PIR415
V. 05 – 15/07/2013 5 ©Velleman nv
Warning: Do not short-circuit any terminals.
8. Reinstall the fuse of the electric circuit and switch it on.
9. To test the PIR sensor, set the light sensitivity to OFF and the
movement sensitivity and 5” to ON. The load should switch on
immediately and – when no movement is detected – switch off
after 5 s.
Caution: DO NOT change the DIP switch settings when power is
connected.
5. Technical Specifications
switch type relay
detection angle 100°
detection range 8 m (@ 22 °C)
rated load max. 800 VA (max. inrush current 3.5A)
power supply 180-240 VAC 50 Hz
working temperature -10 °C to +40 °C
working humidity < 93 % RH
time-delay switch 5 s, 30 s, 1 min, 3 min, 5 min, 8 min
light control < 3 lx to 2000 lx
dimensions visible part Ø 22 x 10 mm
hidden part (controller) 55 x 25 x 35 mm
weight ± 41 g
Use this device with original accessories only. Velleman nv cannot be
held responsible in the event of damage or injury resulting from
(incorrect) use of this device. For more info concerning this product
and the latest version of this manual, please visit our website
www.velleman.eu. The information in this manual is subject to
change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All
worldwide rights reserved. No part of this manual may be copied,
reproduced, translated or reduced to any electronic medium or
otherwise without the prior written consent of the copyright holder.
GEBRUIKERSHANDLEIDING
1. Inleiding
Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat, als
het na zijn levenscyclus wordt weggeworpen, dit toestel
schade kan toebrengen aan het milieu. Gooi dit toestel (en
