9 - HEADPHONE INPUT JACK
Stereo input jack for headphones (∅ 6.35 mm). Verify if the rotary is under 5 before connecting. The output power is
150 mW/8 Ω.
10 - HEADPHONE LEVEL
Used for adjusting the level of the phone's output signal.
D. BACK PANEL
11 - MASTER OUTPUTS
These unbalanced cinch outputs can be connected to any power amplifier. The output voltage suffices to drive any power
amplifier.
12 - GROUND CONNECTOR
To connect 1 or 2 turntables to the ground connectors.
13 - INPUT CONNECTORS
These RCA connectors can be connected to the 3 CD/LINE and the 2 PHONOS. The jacks should be connected to
microphones.
14 - AC INPUT CONNECTOR
AC input connector for the PSU.
5. Technical specifications
inputs
MIKE
(DJ)
1
mV/1k
Ω
PHONO (CH1 – CH2)
3 mV/50k Ω (RIAA)
CD LINE (CH1 – CH3)
150 mV/100k Ω
output (MASTER)
1.5 V/600 Ω (nom.)
harmonic distortion
0.02 % (@ nom. output level)
frequency response
20 Hz ~ 20k Hz ± 0.5 dB (RIAA ± 2 dB)
S/N ratio
MIKE
(DJ)
70
dB
PHONO 70
dB
CD LINE
80 dB
phones
max. 200 mW/8 Ω
voice-over
-14 dB max. @ 1k Hz
power supply
12 VAC/300 mA PSU (incl.)
dimensions
232 x 120 x 32 mm
weight 750
g
Use this device with original accessories only. Velleman nv cannot be held responsible in the event of damage
or injury resulted from (incorrect) use of this device. For more info concerning this product and the latest
version of this manual, please visit our website www.hqpower.eu. The information in this manual is subject to
change without prior notice.
