Specification

• USB 2.0 high speed
• 3.14 Mega Pixel
• Standard SCCB interface (I²C Bus)
• Output support for Raw RGB, RGB565/555, YUV 422 and
JPEG 422 formats
• Supports resolutions: QXGA (2048 x 1536)
• Different fully-automated shutter priority:
- Automatic image control functions including automatic
exposure control (AEC)
- Automatic white balance (AWB)
- Automatic band filter (ABF)
- Automatic black-level calibration (ABLC)
• Image quality controls including color saturation, gamma,
sharpness (edge enhancement), lens correction, white pixel canceling,
noise canceling, and autom. 50/60 Hz luminance detection
• Supports scaling
• Lense: ¼
• Power consumption: active: 90 mA / standby: 0.002 mA
• Low operating voltage 5 V
• Operating temperature: 5 ~ 40 °C
• Relative humidity during operation: max. 20 – 80 %
• Lense dimension: 1/5 inch
• Dimension: 60 x 8 x 5.8 mm (L/W/H)
• Sensitivity: 0.75 V (Lux. sec)
• Signal-to-noise ratio 36 dB
• Dynamic range 62.5 dB
• Auto focus
• Lense: F/2.8
• Frame rates: 30fps @VGA
7.5fps @ QXGA

Optional: item 95843 10 cm connecting cable
item 95878 50 cm connecting cable

Item No. 95933

EAN

4043619959334

Country of origin

China

System requirements

• Windows XP/Vista/Vista-64/7/7-64
• A free USB port

Package content

• USB 2.0 Camera module
• Driver CD
