Delock MiniPCIe I/O PCIe full size 1 x FireWire A, 2 x FireWire B

Description

This miniPCIe adapter by Delock expands your system by
one FireWire A port and two FireWire B ports, which you
can lead out via the slot bracket. You can connect different
FireWire devices like Card Reader, hubs, cameras etc. to
this adapter.

Specification

• Chipset: LSI-LFW643E2
• Form factor: miniPCIe full size
• Interface: PCI Express revision 1.2
• Connector:
internal: 1 x 2 pin power connector
externally on the bracket: 1 x FireWire 1394A 6 pin female
2 x FireWire 1394B 9 pin female
• Data transfer rate:
FireWire A up to 400 Mb/s
FireWire B up to 800 Mb/s
• Supports OHCI specification V1.1
• Hot-Swap
• Cable length with connector:
FireWire ca. 46 cm
power cable ca. 17 cm
• Operating temperature: -10 °C ~ 80 °C
• Storage temperature: -20 °C ~ 95 °C

Item No. 95236

EAN

4043619952366

Country of origin

Taiwan, Republic of

China

System requirements

• Windows 2000/XP/Vista/7/7-64
• Mainboard with a free miniPCIe slot with a PCIe interface
• PC with one free PC slot

Package content

• MiniPCIe module
• Connecting cable
• FireWire bracket
• 1 Molex power cable
• 2 screws
• User manual

Package

• Retail Box
