DeLOCK 54156 User Manual
Ide flash module 44pin 4gb vertical
A r t . 5 4 1 5 6
E A N 4 0 4 3 6 1 9 5 4 1 5 6 0
Specification
• Storage capacity 4GB
• IDE 44pin interface
• Operating voltage 3.3V or 5V
• Operating temperature: -10°C to +70°C
• Endurance 2.000.000 Program / Erase cycles
• Static wear leveling
• Auto Sleep & Power-Down mode
• Integrated ECC function for high reliability of data transfer rate
• PIO Modus 0-6, MWDMA Modus 0-2, UDMA Modus 0-4
• 40MB/s Read, 20MB/s Write
• Power consumption max. 150mA
• Power supply via 22th Pin
• Burst Transfer Rate: 66,6MB/sek.
• MTBF : > 3.000.000 Std.
• Master and Slave switch
• Vibration: 5G ( 7~200Hz)
• Shock: 50G/10ms
• Size: 50,3 x 5,8 x 27,3mm (WxLxH)
Package content
• 4GB IDE Flash module
Package
• antistatic cover
IDE Flash Module 44Pin
4GB vertical
The Delock 4GB 44pin IDE Flash
memory module with its dimensions of
50,3 x 5,8 x 27,3mm very small and
ideal for usage under rough environ-
mental circumstances and for the ap-
plication in computers, Set-Top boxes
and other devices in industry. A safe
data transfer is provided by the inte-
grated Error Correction Code (ECC).
Power-save mode and automatical
shut-down enhance the energy effi-
ciency.
Description
DATA SHEET
W W W.DELOCK.COM
