17 D11T/D11T CD Track-Type Tractor specifications
D11T CD Weights (approximate)
Operating Weight 113 000 kg 248,600 lb
Shipping Weight 75 455 kg 166,000 lb
• Operating Weight: Includes lubricant, coolant, full fuel tank,
hydraulic controls and fluids, 910 mm (36 in) extreme service
shoes, 11 carrydozer, single-shank ripper (optional equipment)
and operator.
• Shipping Weight: Includes lubricants, coolant, 20% fuel,
and ROPS with FOPS cab.
Cab
ISO 3471-1 1986 ROPS
ISO 3471-1 1994 ROPS
ISO 3449 1992 LEVEL II FOPS
• Caterpillar cab and Rollover Protective Structure (ROPS)
are standard in North America, Europe, and Japan.
Sealed and Lubricated Track
Positive Pin Retention (PPR) for extra protection of track seal
in high impact conditions.
Pitch 318 mm 12.5 in
Number Shoes/Side 41
Shoe Type Extreme service
Width of Shoe
D11T 710 mm 28.0 in
D11T CD 910 mm 36.0 in
Length of Track on Ground 4444 mm 14 ft 7 in
Ground Contact Area
D11T 6.3 m 2 9,781 in 2
D11T CD 8.1 m 2 12,581 in 2
Grouser Height
(from ground face of shoe)
102 mm 4.0 in
Ground Clearance 623 mm 24.5 in
Gauge 2896 mm 9 ft 6 in
Features
• Sleeve bearing track
• Lubricant reduces internal bushing wear
• Hydraulic track adjusters; track guiding guards; and large,
positive clamping, two-piece master link are standard
• Improved track joint sealability
• Stronger track link to resist high impact loads
Transmission
1 Forward 3.9 km/h 2.4 mph
2 Forward 6.8 km/h 4.2 mph
3 Forward 11.8 km/h 7.3 mph
1 Reverse 4.7 km/h 5.9 mph
2 Reverse 8.2 km/h 5.1 mph
3 Reverse 14.0 km/h 8.7 mph
Features
• Special modulation system permits fast speed and
direction changes
• 533 mm (21 in) diameter, high torque capacity oil-cooled
clutches
• Exclusive F 37 friction material for excellent life
• Modular transmission, bevel gear, and differential plug
into rear of main drive case
• Two oil-to-water coolers mounted under radiator
• Single-stage torque converter with output torque divider
• Double universal joint eases service
Service Refill Capacities
Fuel Tank 1609 L 425 gal
Optional Fuel Tank 1987 L 505 gal
Cooling System 238.8 L 63 gal
Engine Crankcase 106 L 28 gal
Power Train 344 L 91 gal
Final Drives (each) 30 L 8 gal
Roller Frames (each) 95 L 25.1 gal
Pivot Shaft Compartment 51 L 13.5 gal
Implement Hydraulic 243 L 64 gal
System Tank Only
D11T Weights (approximate)
Operating Weight 104 590 kg 230,100 lb
Shipping Weight 74 4182 kg 163,200 lb
• Operating Weight: Includes lubricant, coolant, full fuel tank,
hydraulic controls and fluids, 810 mm (32 in) extreme service
shoes, 11U ABR bulldozer, single-shank ripper with pin puller
and fast fuel, engine doors (optional equipment) and operator.
• Shipping Weight: Includes lubricants, coolant, 20% fuel,
and ROPS with FOPS cab.
