BENEFITS & FEATURES
Vibratory System
The pod-style vibratory system, proven
reliable on previous soil compactors,
delivers superior compactive force while
offering serviceability advantages.
Proprietary Eccentric Weights
Reliable dual amplitude selection and
innovative design ensure precise
performance.
Cat C6.6 Electronic Diesel Engine
with ACERT Technology
Industry-proven Caterpillar technology
designed to provide unmatched
performance and reliability with ample
power for the most demanding jobs.
CS56 VIBRATORY SOIL COMPACTOR
SPECIFICATIONS
Weights
Operating Weight w/ROPS/FOPS 25,164 lbs
Weight at Drum w/ROPS/FOPS 12,985 lbs
Shipping weight w/ROPS/FOPS 24,989 lbs
Operating Specifications
Drum Width 84 in
Travel Speed (Maximum) 7 mph
Turning Radius Inside Drum Edge 145 in
Turning Radius Outside Drum Edge 229 in
Ground Clearance 21.1 in
Curb Clearance 19.3 in
Blade Cutting Depth 5 in
Engine
Gross Power 156 hp
Engine Model Cat C6.6
Net Power - EEC 80/1269 145 hp
Net Power - ISO 9249 145 hp
Net Power - SAEJ1349 143 hp
Bore 4.13 in
Stroke 5 in
Dimensions
Drum Diameter - Over Drum 60 in
Overall Length 231 in
Overall Length w/Blade 252 in
Overall Width 90 in
Height w/ROPS/FOPS 121 in
Blade height 27 in
Wheelbase 114 in
Tires
23.1" x 26" 8-ply flotation
Service Refill Capacities
Fuel Tank Capacity 91 gal
Vibratory System
Nominal Amplitude - High 0.07 in
Nominal Amplitude - Low 0.035 in
Centrifugal Force Maximum 63,300 lbs
Centrifugal Force Minimum 31,600 lbs
