13 320D FM Specifications
Hydraulic System
Main Implement System – 205 L/min 54.2 gal/min
Maximum Flow (2x)
Max. pressure – Implements 35 000 kPa 5,075 psi
Max. pressure – Travel 35 000 kPa 5,075 psi
Max. pressure – Swing 25 000 kPa 3,625 psi
Pilot System – Maximum flow 41 L/min 10.8 gal/min
Pilot System – Maximum pressure 4,120 kPa 600 psi
Boom Cylinder – Bore 120 mm 4.7 in
Boom Cylinder – Stroke 1260 mm 49.6 in
Stick Cylinder – Bore 140 mm 5.5 in
Stick Cylinder – Stroke 1500 mm 59.3 in
Excavator Linkage
Boom Cylinder – Bore 120 mm 4.7 in
Boom Cylinder – Stroke 1260 mm 49.6 in
Stick Cylinder – Bore 140 mm 5.5 in
Stick Cylinder – Stroke 1500 mm 59.05 in
B1 Family Bucket Cylinder – Bore 120 mm 4.7 in
B1 Family Bucket Cylinder – Stroke 1100 mm 43.3 in
Log Loader Linkage
Boom Cylinder – Bore 140 mm 5.5 in
Boom Cylinder – Stroke 1160 mm 45.7 in
Stick Cylinder – Bore 150 mm 5.9 in
Stick Cylinder – Stroke 1470 mm 57.9 in
Under/Under Heel Cylinder – Bore 130 mm 5.1 in
Under/Under Heel Cylinder – Stroke 1156 mm 45.5 in
Drive
Maximum Travel Speed (HD/LC) 5.3 km/h 3.3 mph
Maximum Drawbar Pull (HD/LC) 188 kN 46,300 lb
Maximum Travel Speed (HW) 4.3 km/h 2.6 mph
Maximum Drawbar Pull (HW) 248 kN 55,700 lb
Swing Mechanism
Swing Torque 61.8 kN·m 45,611 lb ft
Swing Speed 11.5 rpm 11.5 rpm
Engine
Engine Model Cat ® C6.4 ACERT™
Net Flywheel Power 117 kW 157 hp
ISO 9249 110 kW 147 hp
J1349 110 kW 147 hp
EEC 80/1269 110 kW 147 hp
Bore 102 mm 4.02 in
Stroke 130 mm 5.12 in
Displacement 6.4 L 390 in 3
• The 320D FM meets U.S. EPA Tier 3 and EU Stage IIIa
emissions requirements.
• Net power advertised is the power available at the flywheel
when the engine is equipped with fan, air cleaner, muffler,
and alternator.
• No engine derating required below 2300 m (7,500 ft) altitude.
Weights
General Forestry (HD/LC) 25 500 kg 56,228 lb
General Forestry (HW) 26 900 kg 59,315 lb
Log Loader (U/U) 30 300 kg 66,812 lb
• Operating weight with front linkage, with 18 inch riser
and without bucket.
• Operating weight with front linkage, with 48 inch riser
and without grapple.
Service Refill Capacities
Fuel Tank 410 L 108.3 gal
Fuel Tank – Optional Auxiliary 410 L 108.3 gal
Right Front
Maximum Fuel with all 820 L 216.6 gal
Optional Tanks
Cooling System 25 L 6.6 gal
Engine Oil 30 L 7.9 gal
Swing Drive 8 L 2.1 gal
Hydraulic System (including tank) 260 L 68.7 gal
Hydraulic Tank 125 L 33.0 gal
Final Drive (each) – (HD/LC) 10 L 2.6 gal
Final Drive (each) – (HW) 13 L 3.4 gal
Standards
Brakes SAE J1026 APR90
Cab/FOGS/OPS/TOPS/FOPS SAE J1356 FEB88 ISO 10262/
SAE J1084/ISO 8084/
OR-OSHA 437-007-0775/
WCB G602, G603, G604,
G608
