FRONT-WHEEL STEERING COORDINATED STEERING
CRAB STEERING REAR-WHEEL STEERING
STRIKE-OFF TOOLS ADD VERSATILITY,
EASY STORAGE
By using a specific combination of strike-off tools,
the standard tool package allows for 1- to 10-foot
widening. The strike-off tools, supports, and
hydraulic system are designed for use on either
side of the unit. Tool sections have wedge-type
quick-latch connectors. The strike-off tools fold to
allow tool storage within the basic 10-foot
machine width for transport.
STEERING MODES ENSURE MAXIMUM
MANEUVERABILITY
In addition to the three steering modes on the
W730, the rear-wheel steering axle has a manual
override to allow the fourth steering mode or
minor corrections while operating.
SLIDING CONTROL CONSOLE ENHANCES
OPERATOR EASE OF USE
Operators have convenient right- or left-side
access to all machine controls needed for
paving, and console controls are user-friendly
and ergonomically designed.
SEALED CIRCUIT BREAKERS OFFER
ADDED PROTECTION
The electrical system utilizes sealed connections.
Each circuit is protected and can be reset.
BRAKES
Primary braking is accomplished through the
dynamics of the hydrostatic traction drive.
Foot-actuated hydraulic secondary brakes are
integral to the drive axles. Application of the
spring-applied hydraulic release brake can be
performed by the operator.
STANDARD OSCILLATING PUSH ROLLERS
Two bearing-equipped push rollers mounted on
the 112-inch wide oscillating frame compensate
for minor direction misalignment of truck with
road widener.
REMOTELY LOCATED OIL COOLER INCREASES
COOLING CAPACITY
The hydraulically driven oil cooler is thermostatically
controlled and reversible for radiator clean-out.
The remote location isolates the heat from the
engine cooling system.
STRONG HORSEPOWER HELPS BOOST
PRODUCTIVITY
With its powerful 6-cylinder 174 hp Cat engine, the
W730 delivers the muscle to run longer, harder, and
faster and to keep projects moving.
