D5K2Track-TypeTractorSpecifications
Undercarriage
Numberofrollers(eachside) 7
Numberofshoes(eachside)–SALT 40
(SealedandLubricatedTrack)
Undercarriage
Numberofshoes(eachside)– 36
SystemOneUndercarriage
Shoewidth–XL 510mm 20in
Shoewidth–LGP 660mm 26in
Shoewidth–LGP,762mm(30in) 762mm 30in
Lengthoftrackon ground–XL 2310mm 91in
Lengthoftrackon ground–LGP 2310mm 91in
Lengthoftrackon ground–LGP, 2310mm 91in
762 mm(30in)
Trackgauge–XL 1600mm 63in
Trackgauge–LGP 1750mm 69in
Trackgauge–LGP,762mm(30in) 1860mm 73.2in
Groundcontactarea–XL 23562cm 2 3,652in 2
Groundcontactarea–LGP 30492cm 2 4,726in 2
Groundcontactarea–LGP, 35574cm 2 5,514in 2
762mm(30in)
Groundpressure– XL 38.6kPa 5.6psi
Groundpressure– LGP 31.1kPa 4.52psi
Groundpressue–LGP,762mm(30in) 27.1kPa 3.93psi
•Hydraulictrackadjusters.
•Boxsectiontrackrollerframes.
•Bolt-onreartrackguidingguards.
•Fulllengthrecoilguardingwithsprocketguardsandwipers.
•Masterlink–SystemOneandSALT.
•Single-grousershoes.
•Segmentedsprocket(SALT).
•Sealedandlubricatedrollersandidlers.
Standards
Soundlevels:
ISO6396:2008 77dB(A)
SAEJ1166FEB2008 78dB(A)
ROPS SAEJ397-OCT95,
SAE J1040-MAY94,
ISO 3471-94,ISO 3164-95
FOPS SAEJ231-JAN81,
ISO 3449-92
Ripper
Type Parallelogram
Numberofshanks 3
Maximumdigging depth 337.5mm 13.3in
Maximumreachat groundline 555mm 21.9in
Maximumgroundclearanceundertip 448mm 17.6in
Overallwidth 1710mm 67.3in
Height 165mm 6.5in
Weight 554kg 1,222lb
Winch
Weight 610kg 1,345lb
Winchdrive Hydrostatic
Control Hydraulic
Speed Variable
Winchlength 705mm 27.76in
Overallwidth 741mm 29.2in
Drumdiameter 254mm 10in
Drumwidth 274mm 10.8in
Throatclearance 171.5mm 6.75in
Ropediameter–recommended 16mm 0.63in
Ropediameter–optional 19mm 0.75in
Drumcapacity–recommendedcable 113m 371ft
Drumcapacity–optionalcable 78m 256ft
Maximumlinepull– baredrum 18144kg 40,000lb
Maximumlinepull– fulldrum 11340kg 25,000lb
Maximumlinespeed–baredrum 40m/min 131ft/min
Maximumlinespeed–fulldrum 63m/min 207ft/min
•Infinitelyvariablelinespeedandlinepullfrom0tomaximum.
•Powerin/powerout,brakeoff,freespool(standardequipment).
•Singlelever,lowefforthydrauliccontrol.
•Preciseloadcontrolandspeedmodulation.
•Integralmounteddrawbar.
•3rollerfairleadavailable.Kitavailabletoadda4throller.
