WHA-ADP-F8B2-*-P*-Z2(-1)
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49-621-776-0 • USA +1-330-4253555 • Singapore +65-67-799091 • Internet www.pepperl-fuchs.com
1
WirelessHART Adapter
WHA-ADP-F8B2-*-P*-Z2(-1)
4
5
3
2
1
6
7
8
I
?
HAR
T
2-
1+
I
?
HAR
T
6-
3+
5+
4-
V
I
?
HAR
T
4-
2+
3+
5-
V
HAR
T
3-
2+
mA
+
–
HAR
T
Connection
Assembly
• 1-channel
• WirelessHART Adapter
• Battery operated
• Also supplies field device
• Input 2-wire HART transmitters and 2-wire HART current
sources
• Output WirelessHART wireless interface
• Direct mounting on HART- or 4 mA ... 20 mA field device
• Rotatable antenna
Function
The device upgrades a conventional HART or 4 mA ... 20 mA
field device with a WirelessHART interface. It is mounted
either directly to the cable gland entry or separated from the
field device.
The device contains a battery pack which also powers the
field device. Depending on the parameterization, battery
lifetimes up to 5 years are possible. This allows autonomous
measurements. The rotatable antenna can be brought in the
optimal position, regardless of the mounting orientation of the
field device.
The unit is easily programmed with a configuration tool (DTM
or DD).
For additional information, refer to the manual and
www.pepperl-fuchs.com.
Application
The batteries are not included with delivery. Please order
separately.
Features
Front view
Cable gland
optional
Antenna (convertible)
Battery compartment
Connection for
installation on
Field device
