11 Supplement
VEGAPULS 66 standpipe version • 4 … 20 mA/HART - two-wire
36523-EN-121011
Seal Antenna impedance
cone
Process temperature (measured on the process
fitting)
Graphite Ceramic -60 … +250 °C (-76 … +482 °F)
Ceramic -60 … +300 °C (-76 … +572 °F)
Ceramic -60 … +400 °C (-76 … +752 °F)
Vessel pressure relating to the antenna cone
Ʋ PTFE -100 … 4000 kPa/-1 … 40 bar (-14.5 … 580 psi) with
PN 40
Ʋ Ceramic -100 … 16000 kPa/-1 … 160 bar (-14.5 … 2321 psi) with
PN 160
Vessel pressure relating to the flange
nominal stage
see supplementary instructions manual "Flanges ac-
cording to DIN-EN-ASME-JIS"
Vibration resistance 1 g at 5 … 200 Hz according to EN60068-2-6 (vibration
with resonance)
Shock resistance 100 g, 6 ms according to EN 60068-2-27 (mechanical
shock)
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Options of the cable entry
Ʋ Cable gland M20 x 1.5 (cable: ø 5 … 9 mm)
Ʋ Cable entry ½ NPT
Ʋ Blind stopper M20 x 1.5; ½ NPT
Ʋ Closing cap M20 x 1.5; ½ NPT
Plug options
Ʋ Signal circuit M12 x 1, according to ISO 4400, Harting HAN, 7/8" FF
Ʋ Indication circuit M12 x 1
Wire cross-section (spring-loaded terminals)
Ʋ Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Electromechanical data - version IP 66/IP 68 (1 bar)
Options of the cable entry
Ʋ Cable gland with integrated connec-
tion cable
M20 x 1.5 (cable: ø 5 … 9 mm)
Ʋ Cable entry ½ NPT
Ʋ Blind stopper M20 x 1.5; ½ NPT
Connection cable
Ʋ Wire cross-section 0.5 mm² (AWG 20)
Ʋ Wire resistance < 0.036 Ω/m
Ʋ Tensile strength < 1200 N (270 lbf)
Ʋ Standard length 5 m (16.4 ft)
Ʋ Max. length 180 m (590.6 ft)
Ʋ Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F)
