Technical Data KFD2-SR2-Ex2.W
103
36
8_
EN
G.xm
l
2
003
-06-
0
3
Supply
Connection Power Rail or terminals 14+, 15-
Rated voltage 20 ... 30 V DC
Ripple ≤ 10 %
Rated current ≤ 50 mA
Power loss 0,7 W
Power consumption < 1,3 W
Input
Connection terminals 1+, 2+, 3-; 4+, 5+, 6-
Rated values acc. to IEC 60947-5-6 (NAMUR, DIN 19234), see system description for electrical data
Open circuit voltage/Short-circuit current approx. 8 V DC / approx. 8 mA
Switching point/Switching hysteresis 1,2 ... 2,1 mA / approx. 0,2 mA
Pulse/Pause ratio ≥ 20 ms / ≥ 20 ms
Lead monitoring breakage I ≤ 0,1 mA , short-circuit I > 6 mA
Output
Connection output I: terminals 7, 8, 9 ; output II: terminals 10, 11, 12
Output I and II signal ; relay
Contact loading 253 V AC / 2 A / cos ϕ > 0.7; 126.5 V AC / 4 A / cos ϕ > 0.7; 40 V DC / 2 A resistive load
Energised/De-energised delay approx. 20 ms / approx. 20 ms
Mechanical life 10 7 switching cycles
Transfer characteristics
Switching frequency ≤ 10 Hz
Electrical isolation
Output/Power supply reinforced insulation according to IEC 61140, rated insulation voltage 300 V eff
Output/Output from january 2002 reinforced insulation according to IEC 61140, rated insulation voltage 300 Veff
Standard conformity
Climatic conditions acc. to DIN IEC 721
Directive conformity
Electromagnetic compatibility standards
Directive 89/336/EG EN 61326, EN 50081-2, NE 21
Ambient conditions
Ambient temperature -20 ... 60 °C (253 ... 333 K)
Mechanical specifications
Protection degree IP20
Mass approx. 150 g
Data for application in conjunction
with hazardous areas
EC-Type Examination Certificate PTB 00 ATEX 2080 , for additional certificates see www.pepperl-fuchs.com
Group, category, type of protection ¬ II (1) G D [EEx ia] IIC [circuit(s) in zone 0/1/2]
Input EEx ia IIC
Voltage U 0 10,5 V
Current I 0 13 mA
Power P 0 34 mW (linear characteristic)
Supply
Safety maximum voltage U
m
253 V AC / 125 V DC (Attention! U
m
is no rated voltage.)
Type of protection [EEx ia and EEx ib]
Explosion group IIA IIB IIC
External capacitance 75 µF 16,8 µF 2,41 µF
External inductance 1000 mH 840 mH 210 mH
Statement of conformity TÜV 99 ATEX 1493 X , observe statement of conformity
Group, category, type of protection,
Temperature classification ¬ II 3 G EEx nAC IIC T4 [device in zone 2]
Output
Contact loading 253 V AC / 2 A / cos ϕ > 0.7; 126.5 V AC / 4 A / cos ϕ > 0.7; 40 V DC / 2 A resistive load (PTB 00 ATEX 2080)
50 V AC / 4 A / cos ϕ > 0.7; 40 V DC / 2 A resistive load (TÜV 99 ATEX 1493 X)
Safety maximum voltage U m 253 V AC (Attention! The rated voltage can be lower)
Electrical isolation
Input/Input not available
Input/Output safe electrical isolation acc. to EN 50020, voltage peak value 375 V
Input/Power supply safe electrical isolation acc. to EN 50020, voltage peak value 375 V
Directive conformity standards
Directive 94/9 EU EN 50014, EN 50020, EN 50021
Entity parameter
Certification number J.I.3002773
FM control drawing No. 116-0035
Suitable for installation in division 2 yes
