10 Supplement
VEGABAR 51 • Profibus PA
36714-EN-130321
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
Gauge pressure
0 … +5.801 psig
+29.00 psig -14.50 psig
0 … +14.50 psig +145.0 psig -14.50 psig
0 … +36.26 psig +507.6 psig -14.50 psig
0 … +1450 psig +2901 psig -14.50 psig
0 … +3626 psig +7252 psig -14.50 psig
0 … +5802 psig +17404 psig -14.50 psig
0 … +72.52 psig +507.6 psig -14.5 psig
0 … +145.0 psig +1160 psig -14.50 psig
0 … +362.6 psig +1160 psig -14.50 psig
0 … +580.2 psig +1160 psig -14.50 psig
0 … +870.2 psig +2901 psig -14.50 psig
-14.50 … 0 psig +145.0 psig -14.50 psig
-14.50 … +1.5 psig +311.8 psig -14.50 psig
-14.50 … +362.6 psig +507.6 psig -14.50 psig
-14.50 … +145.0 psig +1160 psig -14.50 psig
-14.50 … +362.6 psig +1160 psig -14.50 psig
-14.50 … +870.2 psig +2901 psig -14.50 psig
-2.901 … +2.901 psig +2.901 psig -14.50 psig
-7.252 … +7.252 psig +145.0 psig -14.50 psig
Absolute pressure
0 … 14.50 psi
145.0 bar 0 psi
0 … 36.26 bar 507.6 psi 0 psi
0 … 72.52 psi 507.6 psi 0 psi
0 … 145.0 bar 1160 psi 0 psi
0 … 362.6 psi 1160 bar 0 psi
Reference conditions and actuating variables (according to DIN EN 60770-1)
Reference conditions according to DIN EN 61298-1
Ʋ Temperature +18 … +30 °C (+64 … +86 °F)
Ʋ Relative humidity 45 … 75 %
Ʋ Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psi)
Determination of characteristics Limit point adjustment according to IEC 61298-2
Characterstic curve Linear
Reference installation position upright, diaphragm points downward
Influence of the installation position depending on the chemical seal version
