10 Supplement
VEGABAR 52 • Foundation Fieldbus
36720-EN-130321
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
-0.5 … +0.5 bar/-50 … +50 kPa +35 bar/+3500 kPa -1 bar/-100 kPa
Absolute pressure
0 … 0.1 bar/0 … 10 kPa
15 bar/1500 kPa 0 bar abs.
0 … 1 bar/0 … 100 kPa 35 bar/3500 kPa 0 bar abs.
0 … 2.5 bar/0 … 250 kPa 50 bar/5000 kPa 0 bar abs.
0 … 5 bar/0 … 500 kPa 65 bar/6500 kPa 0 bar abs.
0 … 10 bar/0 … 1000 kPa 90 bar/9000 kPa 0 bar abs.
0 … 25 bar/0 … 2500 kPa 130 bar/13000 kPa 0 bar abs.
0 … 60 bar/0 … 6000 kPa 200 bar/20000 kPa 0 bar abs.
Nominal measuring ranges and overload capacity in psi
The specifications are only an overview and refer to the measuring cell. Limitations due to the ma-
terial and version of the process fitting are possible. The specifications on the nameplate apply.
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
Gauge pressure
0 … +1.450 psig
+217.6 psig -2.900 psig
0 … +2.901 psig +290.1 psig -5.802 psig
0 … +5.802 psig +435.1 psig -11.60 psig
0 … +14.50 psig +507.6 psig -14.5 psig
0 … +36.26 psig +725 psig -14.50 psig
0 … +72.52 psig +942.7 psig -14.50 psig
0 … +14.50 psig +1305 psig -14.50 psig
0 … +362.6 psig +1885 psig -14.50 psig
0 … +870.2 psig +2901 psig -14.50 psig
-14.5 … 0 psig +507.6 psig -14.50 psig
-14.5 … +21.76 psig +725.2 psig -14.5 psig
-1 … +72.52 psig +942.7 psig -14.5 psig
-14.50 … +145.0 psig +1305 psig -14.50 psig
-1 … +362.6 psig +1885 psig -14.5 psig
-1 … +870.2 psig +2901 psig -14.50 psig
-0.725 … +0.725 psig +217.6 psig -2.901 psig
-1.450 … +1.450 psig +290.1 psig -5.801 psig
-2.901 … +2.901 psig +435.1 psig -11.60 psig
-7.252 … +7.252 psig +507.6 psig -14.50 psig
Absolute pressure
0 … 1.405 psi
217.6 psi 0 psi
0 … 14.5 psi 507.6 psi 0 psi
