9 Supplement
VEGACAP 35 • - Relay (DPDT)
33759-EN-130916
9 Supplement
9.1 Technical data
General data
Material 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
Ʋ Process fitting - thread St 37, 316Ti or Aluminium
Ʋ Process seal Klingersil C-4400
Ʋ insulation (partly insulated) PE/PA 12
Ʋ Probe (cable PE/PA 12 partly insu-
lated: ø 6 mm/0.236 in)
316L
Ʋ Gravity weight 316L
Materials, non-wetted parts
Ʋ Housing Plastic PBT (polyester), Alu die-casting powder-coated
Ʋ Seal between housing and housing
cover
Silicone (Aluminium/plastic housing)
Ʋ Ground terminal 316L
Process fittings
Ʋ Pipe thread, cylindrical (DIN 3852-A) G1½ A
Ʋ American pipe thread, conical
(ASME B1.20.1)
1½ NPT
Weight
Ʋ Instrument weight (depending on
process fitting)
0.8 … 4 kg (0.18 … 8.82 lbs)
Ʋ Gravity weight approx. 900 g (32 oz)
Ʋ Cable weight: ø 6 mm (0.236 in) approx. 180 g/m (1.9 oz/ft)
Sensor length (L) 400 … 20000 mm (15.75 … 787.4 in)
Active tip (gravity weight) 200 mm (7.874 in)
Max. tensile load (cable)
Ʋ PE/PA 12 partly insulated: ø 6 mm
(0.236 in)
10 KN (2248 lbs)
Max. torque (process fitting - thread) 100 Nm (74 lbf ft)
Measuring frequency 430 kHz
Output variable
Output
Relay output (DPDT), 2 floating spdts
Switching voltage
Ʋ Min. 10 mV
Ʋ Max. 253 V AC, 253 V DC
With circuits > 150 V AC/DC, the relay contacts must be
in the same circuit.
Switching current
Ʋ Min. 10 µA
