9 Supplement
9 .1 Technical data
General data
Materials 316Ti corresponds to 1.4571, 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
-
Process fitting PP
-
Process seal Klingersil C-4400
-
insulation (partly insulated) FEP
-
Probe (cable FEP partly insulated:
ø
2.5 mm/0.098 in)
316Ti
Materials, non-wetted parts
-
Housing PP
-
Housing cover PBT
-
Seal between housing and housing
cover NBR
-
Cable gland PA
Process fitting G1½ A (ISO 228 T1)
Weight
-
with plastic housing 500 g (17.6 oz)
-
Cable weight: ø 2.5 mm (0.098 in) 40 g/m (0.4 oz/ft)
Sensor length (L1 - L5) 0.22 … 50 m (0.722 … 164.04 ft)
Insulation length 78 mm (3 in)
Output variable
Suitable signal conditioning instruments VEGATOR 256C, 532, 631
Ambient conditions
Ambient temperature on the housing -40 … +80 °C (-40 … +176 °F)
Storage and transport temperature -40 … +80 °C (-40 … +176 °F)
Process conditions
Process pressure -1 … 6 bar/-100 … 600 kPa (-14.5 … 87 psig)
Process temperature EL 6 of 316L -20 … +100 °C (-4 … +212 °F)
Conductive of the medium min. 7.5 µS/cm
Electromechanical data
Cable entry 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm/
0.2 … 0.35 in)
