Error Cause Rectification
Incorrect termina-
tion Check termination at the beginning
and end points of the bus and termin-
ate, if necessary, according to the
specification
Instrument not
connected to the
segment Check and correct, if necessary
In Ex applications, the regulations for the wiring of intrinsically safe
circuits must be observed.
The indicating and adjustment modules indicates faults via error codes
and text messages. The following table describes the error codes with
status according to NE 107 and gives information on the causes of
failure and their removal:
Status accor-
ding to NE 107 Error code Text message Cause/Rectification
Failure E 013 no measured value available Sensor in boot phase
no measured value available Sensor does not find an echo, e.g.
due to faulty installation or wrong
parameter adjustment
no measured value available Wrong sensor length entered
E 017 Adjustment span too small Adjustment not within the specifica-
tion. Carry out the adjustment again,
increasing the distance between
min. and max. adjustment
E 036 No operable software Failed or interrupted software up-
date/Repeat software update
E 042 Hardware error, electronics defec-
tive Exchange the instrument or send it
in for repair
E 043 Hardware error, electronics defec-
tive Exchange the instrument or send it
in for repair
E 113 Communication conflict Exchange the instrument or send it
in for repair
8 .3 Exchanging the electronics module
If the electronics module is defective, it can be replaced by the user.
In Ex applications only one instrument and one electronics module with
respective Ex approval may be used.
Error messages via the
indicating and adjust-
ment module
36 VEGAFLEX 67 • Foundation Fieldbus
8 Maintenance and fault rectification
