DN
D
D1
D2
b
h
d
32 (1.26)
135
(5.315)
100
(3.937)
78
(3.071)
16 (0.63)
2 (0.079)
4 x ø 18
(0.709)
40
(1.575)
145
(5.709)
110
(4.331)
88
(3.465)
16 (0.63)
3 (0.118)
4 x ø 18
(0.709)
50
(1.969)
160 (6.3)
125
(4.921)
102
(4.016)
17
(0.669)
3 (0.118)
4 x ø 18
(0.709)
65
(2.559)
180
(7.087)
145
(5.709)
122
(4.803)
19
(0.748)
3 (0.118)
8 x ø 18
(0.709)
80 (3.15)
195
(7.677)
160
(6.299)
133
(5.236)
21
(0.827)
3 (0.118)
8 x ø 18
(0.709)
100
(3.937)
230
(9.055)
190
(7.480)
158
(6.221)
23
(0.906)
3 (0.118)
8 x ø 22
(0.866)
125
(4.921)
270
(10.63)
220
(8.661)
184
(7.244)
25
(0.984)
3 (0.118)
8 x ø 26
(1.024)
150
(5.906)
300
(11.81)
250
(9.843)
212
(8.347)
27
(1.063)
3 (0.118)
8 x ø 26
(1.024)
200
(7.874)
375
(14.76)
320
(12.6)
285
(11.22)
35
(1.378)
3 (0.118)
12 x ø 30
(1.181)
250
(9.843)
445
(17.52)
385
(15.16)
345
(13.58)
39
(1.535)
3 (0.118)
12 x ø 33
(1.299)
Tab. 21: Dimensions - GOST flange PN 40. All distance values in mm (in)
PN 63
DN
D
D1
D2
b
h
d
25
(0.984)
135
(5.315)
100
(3.937)
68
(2.677)
20
(0.787)
2 (0.079)
4 x ø 18
(0.709)
32 (1.26)
150
(5.906)
110
(4.331)
78
(3.071)
21
(0.827)
2 (0.079)
4 x ø 22
(0.866)
40
(1.575)
165
(6.496)
125
(4.921)
88
(3.465)
21
(0.827)
3 (0.118)
4 x ø 22
(0.866)
50
(1.969)
175
(6.89)
135
(5.315)
102
(4.016)
23
(0.906)
3 (0.118)
4 x ø 22
(0.866)
65
(2.559)
200
(7.874)
160
(6.299)
122
(4.803)
25
(0.984)
3 (0.118)
8 x ø 22
(0.866)
80 (3.15)
210
(8.268)
170
(6.693)
133
(5.236)
27
(1.063)
3 (0.118)
8 x ø 22
(0.866)
100
(3.937)
250
(9.843)
200
(7.874)
158
(6.221)
29
(1.142)
3 (0.118)
8 x ø 26
(1.024)
125
(4.921)
295
(11.61)
240
(9.449)
184
(7.244)
33 (1.3)
3 (0.118)
8 x ø 30
(1.181)
