4 mounting, 1 general instructions, 2 mounting instructions – VEGA VEGABOX 01 User Manual
Page 8
4 Mounting
4.1 General instructions
VEGABOX 01 can be mounted in any position. However,
vertical mounting is recommended. This avoids pollution of the
breather facility and moisture penetration.
Note:
There must be the same atmospheric pressure on the breather
facility as well as on the measurement loop. Otherwise the
measured value can be adulterated.
Use the recommended cables (see chapter "Connecting to
power supply") and tighten the cable gland.
4.2 Mounting instructions
VEGABOX 01 can be mounted as follows:
l
on carrier rail 35x7.5 according to EN 50022
l
on mounting plate or on the wall
Installation position
Moisture
Mounting versions
8
VEGABOX 01
Mounting
32771
-EN
-061121
