3 Product description
3.1 Configuration
The scope of delivery encompasses:
l
19" module card VEGALOG 571 AA
l
Documentation
- this operating instructions manual
3.2 Principle of operation
The AA card (Ausgang Analog, i.e. output analogue) provides
together with the VEGALOG 571 processing system ten 0/
4 … 20 mA outputs. These can be used for transmission of the
measuring results to the following instruments:
l
Indicating instruments
l
Characteristics recorder
l
Controller
l
PLC
The AA card makes the processing results available via up to
ten analogue currents in the range of 0 … 20 mA. A scaling as
well as the definition as rising or falling characteristics can be
set via the adjustment software.
The module card is powered via the common power supply
unit of the VEGALOG system.
You can find detailed information on the power supply in the
"Technical data" in the "Supplement".
3.3 Operation
The operation of VEGALOG 571 is carried out via a PC which
can be connected via the RS232 interface of the CPU. As an
alternative, connection via Ethernet and VEGACOM 558 is
possible.
The adjustment software PACTware™ with the corresponding
DTMs is installed under Windows™ and ensures easy
configuration of measuring systems as well as parameter
adjustment of connected VEGA sensors. For this purpose,
PACTware™ provides a clear adjustment interface with menu
structure, window technology and graphic support. In addition,
online help is available which describes the available functions
Scope of delivery
Area of application
Physical principle
Power supply
