3 P roduct description
3 .1 Configuration
The scope of delivery encompasses:
l
Lock fitting ARV-SG63.2 for VEGASWING 63 vibrating
level switch
l
Documentation
-
this operating instructions manual
3 .2 Principle of operation
ARV-SG63.2 is a pressure-tight threaded fitting up to 16 bar
(232 psig) and can be used together with a level sensor in tube
version (VEGASWING 63). The tube version of the sensor
must have a diameter of 21.3 mm (ø 0.84 in).
ARV-SG63.2 cannot be used in coated tube extensions.
The wetted parts of ARV-SG63.2 are made of steel (316L).
With the lock fittings, sensors with tube extension can be fixed
infinitely.
The pressure screw of the lock fitting compresses a graphite
gasket consisting of three rings axially which is then pressed
radially to the tube of the sensor. If mounted correctly, the
graphite gasket encircles the tube tightly. The clamp protects
the tube against sliding through. A locking bracket protects the
terminal screws of the clamp against unauthorised or
unintentional loosening.
3 .3 Packaging, transport and storage
Your instrument was protected by packaging during transport.
Its capacity to handle normal loads during transport is assured
by a test according to DIN EN 24180.
The packaging of standard instruments consists of environ-
ment-friendly, recyclable cardboard. For special versions, PE
foam or PE foil is also used. Dispose of the packaging material
via specialised recycling companies.
Transport must be carried out under consideration of the notes
on the transport packaging. Nonobservance of these instruc-
tions can cause damage to the device.
Scope of delivery
Area of application
Functional principle
Packaging
Transport
