Sensor length (L) - suspension cable FEP
(-40 … +150 °C/-40 … +302 °F) 0.6 … 80 m (1.969 … 262.47 ft)
Output variable
Output Contactless electronic switch
Modes (switchable) min./max.
Switching delay
-
When immersed 0.5 s
-
When laid bare 1 s
Ambient conditions
Ambient temperature on the housing -40 … +80 °C (-40 … +176 °F)
Storage and transport temperature -40 … +80 °C (-40 … +176 °F)
Process conditions
Measured variable Limit level of solids
Process pressure -1 … 6 bar/-100 … 600 kPa (-14.5 … 87 psig)
Process temperature with PUR suspension
cable -20 … +80 °C (-4 … +176 °F)
Process temperature with FEP suspension
cable -40 … +150 °C (-40 … +302 °F)
Product density
-
Standard > 0.05 g/cm³ (0.002 lbs/in³)
-
adjustable > 0.02 g/cm³ (0.0007 lbs/in³)
Granular size no limitation 1)
Electromechanical data
Cable entry/plug (dependent on the version)
-
Single chamber housing l
1 x cable entry M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; attached 1 x cable
entry M20 x 1.5
or:
l
1 x cable entry ½ NPT, 1 x blind stopper ½ NPT,
1 x cable entry ½ NPT
or:
l
1 x plug M12 x 1; 1 x blind stopper M20 x 1.5
Spring-loaded terminals for wire cross-section up to 1.5 mm² (AWG 16)
Adjustment elements
Mode switch
-
Min. Min. detection or dry run protection
1) max. 20 mm (0.8 in) with product density < 0.05 g/cm³ (0.002 lbs/in³).
