APPLICATION
OF ACCESSORIES
The sucking hose is a basic element of the vacuum cleaner equipment. Its
flexibility enables easy manipulation with other accessories.
The endings of the hose are connected so that they prevent twisting the
hose during operation. There is an inlet with suction power adjustment at one
of the endings.
Telescope suction tube connects the nozzles and brushes with sucking
hose extending the distance of cleaning area. The tube construction makes
possible to adjust its length during cleaning depending on the size of the
User.
You can achieve desired length moving „A” button in direction indicated by
the arrow. Maximum tube length = 96 cm.
Accessories, such as nozzles: small land gap and small brush are placed in
the accessories compartment under the front lid of the vacuum cleaner.
Small nozzle is intended for vacuuming soft surfaces such as:
curtains, draperies, upholstered furniture etc.
Small brush is intended for vacuuming rough
surfaces such as: libraries, picture frames etc.
Gap nozzle is intended for picking up dirtiness from places of difficult access like the
gaps in panelling, skirting, heaters, etc.
Nozzle- brush is universal element of equipment. It can be used both as a brush
and as a nozzle. You can change it switching appropriate button. Pressing button
backwards
(marked at the housing) makes the brush appear from the casing, it
can be used for vacuuming hard surface, i.e. wooden floors, laminates, tiles or walls.
Pressing button forwards
(marked at the housing) The nozzle brush is prepared
for operation as a nozzle and it is intended for soft surface cleaning, i.e. carpets, fitted carpets.
„BNB” – „Brush Natural Bristle”
It is used for cleaning and polishing hard surfaces, sensitive for scratching, i.e.
wooden floor, laminate, parquet, marble, tiles, walls, coverings made of noble
materials, etc.
Gentle and soft natural bristle provides maximum vacuuming efficiency and protects
against scratching cleaned surface.
Small nozzle
Gap nozzle
Small brush
Telescope extension tube
Wąż ssący
SAFBAG (bag)
Separator
49.4000
Water
measuring vessel
Nozzle-brush
Initial filter
Black
surface
Foam neutralizing
agent
Accessories
cover
Cable rewind
button
Water filter unit
Air recilculation
module knob
Back water
tank
Pipe node
Initial filter
On/off
button
SAFBAG (bag)
unit
