STM SatLink Hub Family - Manual (Page 3)

SatLink Hub Family
9300 9400 9800
Forward Link DVB-S2 DVB-S2 DVB-S2
Return Link DVB-RCS2 DVB-RCS2 DVB-RCS2
Forward Link ACM & QoS   
Return Link ACM & QoS   
Max # of Beams 10 10 10
# of VSATs 0-1000 0-1000 0-50000
Redundancy N:1 or 1:1 N:1 or 1:1
VNO   
VSN   
Return SCPC Mode   
TCP Acceleration   
Accounting Support   
Mesh Topology Optional Optional 
Commercial TRANSEC Optional Optional Optional
Forward Automatic UPC Optional Optional Optional
Rack Space* Half-Rack (22U) 1 to 2 Racks (42U) 1 to 3 Racks (42U)
Easily Upgradable  (to 9400)  (to 9800)
*Recommended rack space with room to grow. For a SatLink 9800 Hub expecting 8 or more beams, 3 racks (42 U each) are recommended.
SatLink Hub Feature Comparison
SatLink Hub Family
9300 9800 9400
Example Configurations
(including 1 test VSAT per beam)
