Ulpt-l, Line drawing – Omnimount ULPT-L Sales Sheet User Manual

Page 3

background image

inches (mm)

800.MOUNT.IT (800.668.6848)

10202010

FRONT VIEW

MOUNTING PROFILE

PANEL ATTACHMENT -

VESA COMPATABILITY (mm)

WALL MOUNTING

35

(890)

35

(890)

500

200 - 800

32.4

(822)

15

(381)

19.6

(498)

19.6

(498)

22.5

(570)

1.4

(36)

1.3

(34)

R .20

(5)

Ø 8

100

2.3

(58)

0˚ to +15˚

ULPT-L

line drawing
