inches (mm)
FRONT VIEW
WITH ADAPTERS
VESA BRACKET (mm)
WITH ADAPTERS
(7.9)
200
(7.9)
200
23.6
(600)
15.7
(400)
15.7
(400)
11.8
(300)
11.8
(300)
(3.9)
100
(3.9)
100
VESA BRACKET
WALL MOUNT BRACKET
22.6
(574)
6.9
(176)
11.8
(300)
1.7
(42)
10.0
(254)
16.0
(406)
3.1
(81)
16.6
(423)
17.2
(437)
25.0
(634)
6.7
(169)
Ш.3
(7)
Ш.3
(8)
Ш.4
(9)
3.0
(76)
0.8
(21)
6.6
(169)
16.5
(418)
2.4
(60)
12.9
(329)
FRONT VIEW
SIDE VIEW
WITH ADAPTERS
SIDE VIEW
10°
3°
TILT RANGE
OS120FM
technical data sheet
Packaging UPC MC UPC
Americas 698833019988 10698833019985
International 698833019988 10698833019985
Box Contents Qty
Wall plate 1
Arm assembly 1
Cable management 1
Monitor plate 1
800.MOUNT.IT (800.668.6848)
04052013
Box Contents Qty
Tilt tension handle 1
Spider 46 adapter 4
Instruction manual 1
Complete hardware kit 1
Dimensions WxDxH Inches (mm) Wt lbs (kg) Qty
Box 27.1 x 4.3 x 15.2 (689x109x385) 18 (8.2) NA
MC 27.5 x 18.1 x 16.2 (700x460x412) 75 (33.8) 2
