inches (mm)
4N1-M
technical data sheet
11.2
(284)
16.3
(415)
14.4
(364)
4.2
(106)
4.5
(113)
17.1
(435)
2.4
(60)
5.4
(138)
9
(228)
1.2
(30)
.9
(22)
20.6
(523)
14.6
(371)
FRONT VIEW MOUNTING PROFILE
MAXIMUM EXTENSION
100
200
100 200
6
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
Ø.33
(8)
WALL MOUNTING
FRONT VIEW
WITH ADAPTERS
MOUNTING PROFILE
WITH ADAPTERS
MAXIMUM EXTENSION
WITH ADAPTERS
300
400
300 400
8
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
WITH ADAPTERS
+15° TO -5°
800.MOUNT.IT (800.668.6848)
10252011
Box Contents Qty
Wall plate 1
Wall plate cover 1
Arm 1
VESA adapter 1
Box Contents Qty
Complete mount installation hardware kit 1
Complete panel attachment hardware kit 1
Instruction manual 1
TV compatibility chart 1
Color Packaging UPC MC UPC
Americas Black 728901022654 728901716102
International NA NA NA
Dimensions WxDxH inches(mm) Wt (kg) Qty
Box 13.2 x 18.9 x 4.5 (335x480x115) 13.7 (6.2) NA
MC 13.8 x 19.5 x 9.5 (350x495x240) 12.7 2
