Omnimount CL-L Sales Sheet User Manual
Cl-l, Series, Product information sheet

Series
800.MOUNT.IT (800.668.6848)
UCL-X
2005 Custom Retailer
EXC!TE Award
2005 CEDIA Manufacturers’
Excellence Award
2006 RESI Award Winner
UCL-L
CL-L
CL-M
CL-S
05112010
OmniMount, an innovator of A/V mounts and furniture for more
than a quarter century, is the choice of professional installers
and the brand most recommended by flat panel manufacturers.
The popular Architectural Series is a full line of cantilever mounts
with innovation, durability and maximum functionality built
right in. The CL-L is ideal for anyone requiring a large
heavy-duty cantilever mount with advanced features.
CL-L
product information sheet
A double-capacity cable management system
is seamlessly integrated into the CL-L, allowing
for twice as many cables to be neatly tucked
away within the cantilever’s housing
Product Specifications
Fits most: 32” - 45” flat panels
Supports up to: 125 lbs (56.7 kg)
Tilt: -5º to +15º
Mounting profile: 5.32” (135mm)
Maximum extension: 26.81” (681mm)
VESA Compliant: 100x100 to 200x200
Mounting: Double-stud
Warranty: 5 years
Color: Black and Platinum
Product Benefits
•
Tilt, pan and swivel for maximum
viewing flexibility
•
Die-cast aluminum construction for
maximum support in a lightweight mount
•
I-beam arm design for added strength
•
Innovative 4-link tilt mechanism for
smooth, effortless movement
•
Double-capacity cable management
system guides wires
•
Built-in screen leveling
•
Lift n’ Lock
™
allows you to easily
attach your flat panel to the mount
•
Sliding lateral on-wall adjustment
•
Wall plate equipped with dual
gang J-Box cutouts
•
Locking system secures panel to mount
•
Rotate for portrait or landscape orientation
•
Installation template for simple
and accurate mounting
•
Includes complete hardware kit
