inches (mm)
FRONT VIEW SIDE VIEW
19.9
(505)
6.8
(173)
19.8
(503)
26.3
(667)
13.9
(352)
Ø 0.3
(9)
1.6
(41)
1.2
(30)
11.5
(292)
15
(381)
17
(431)
21.5
(545)
29.8
(758)
16.7
(425)
6.9
(176)
26.1
(664)
29.7
(755)
14.1
(357)
3.9
(100)
6.1
(154)
16.7
(425)
TOP VIEW
100
200
7
200
VESA BRACKET (mm)
FRONT VIEW
WITH ADAPTERS
SIDE VIEW
WITH ADAPTERS
600
300
400
300 400
8
VESA BRACKET (mm)
WITH ADAPTERS
TOP VIEW
WITH ADAPTERS
WALL MOUNT BRACKET
PLAY70DS
technical data sheet
Packaging UPC MC UPC
Americas 698833035155 10698833035152
International 698833035155 10698833035152
Box Contents Qty
Arm 1
Wall plate 1
Wall plate cover 2
Wall plate hardware 1
Rear arm cover 2
800.MOUNT.IT (800.668.6848)
05292013
Box Contents Qty
200x200 VESA bracket 1
Spider adapter 4
Instruction manual 1
Complete hardware kit 1
Dimensions WxDxH Inches (mm) Wt lbs (kg) Qty
Box 30.5 x 13 x 8 (775x330x200) 31.5 (14.3) NA
MC 31 x 17 x 14 (787x432x356) 65.5 (29.7) 2
