Omnimount CL-M Manual ru User Manual
Page 21
P21
STEP 7 – VESA PLATE & VA324 ADAPTER
B
A
200mm
100mm
OPTION B
OPTION C – 200mm x 400mm, 200mm x 300mm, 100mm x 300mm
OPTION D – 300mm x 200mm
OPTION C/D
C/D
300mm
400mm
200mm
100mm
300mm
400mm
200mm
400mm
300mm
100mm
200mm
200mm
300mm
OPTION B – 400mm x 400mm, 300mm x 400mm,
300mm x 300mm, 200mm x 300mm
OPTION B – 200mm x 200mm, 100mm x 100mm
