inches (mm)
4.2
(108)
Ø 0.3
(8)
5.5
(139)
6.5
(165)
0.4
(10)
0.4
(11)
9.4
(240)
10.3
(262)
12.2
(310)
20.2
(514)
2.7
(69)
24
(610)
10.7
(271)
20.1
(511)
FRONT VIEW
SIDE VIEW
9.5°
TILT RANGE WALL MOUNTING
300 - 400
8.4
400.0 100.0
494.2
67.0
VESA BRACKETS (mm)
200.0
100.0
8.4
VESA BRACKETS (mm)
WITH ADAPTERS
LIFT70
technical data sheet
Packaging UPC MC UPC
Americas 698833038309 10698833038306
International 698833038309 10698833038306
800.MOUNT.IT (800.668.6848)
06262013
Box Contents Qty
Vertical rail 2
Horizontal rail 4
Tilt tension knob 2
Lift assembly 1
Box Contents Qty
Wall template 1
200mm x 200mm adapter 2
Instruction manual 1
Complete hardware kit 1
Dimensions WxDxH Inches (mm) Wt lbs (kg) Qty
Box 29 x 4 x 20.7 (737x102x525) 36.4 (16.5) NA
MC 30.3 x 4.3 21.3 (770x110x540) 36.4 (16.5) 1
