CONTENTS
1
2
3
4
2
Wall Template 1 5
Covers 2 4
Security Bar 1 3
Vertical Rails 2 2
Wall Plate 1 1
N/A
Contents
Wall Kit 516-4vC
Description Qty Part # Pouch #
Lag Bolts 4 W-A W-A
Steel Washers 4 W-B W-B
Wall Anchors 4 W-C W-C
M-J
W-A W-B W-C
M-A M-B M-C M-D M-E
M-F M-G M-H
M-I
M-L M-K
SCREWS / HARDWARE FOR FLAT PANEL
(Monitor Kit L-U-vD)
Part # Qty Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round Spacers: M6-M8 x 5mm
M-J 4 Round Spacers: M6-M8 x 10mm
M-K 4 Round Washers: M4-M5
M-L 4 Round Washers: M6-M8
