NC80C
technical data sheet
inches (mm)
400
300
300 400
9
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
WITH ADAPTERS
100
100 7
200
200
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
FRONT VIEW
WITH ADAPTERS
MAXIMUM EXTENSION
WITH ADAPTERS
MOUNTING PROFILE
WITH ADAPTERS
.4
(10)
Ø .3
(8)
R.2
(4)
2.6
(66)
1.3
(33)
10
(254)
2x 4.6
(117)
1.2
(30)
.2
(6)
17.2
(437)
17.2
(437)
16.3
(414)
3.6
(90)
3.4
(86)
16.1
(409)
2.9
(74)
10.3
(263)
10.3
(263)
FRONT VIEW
MAXIMUM EXTENSION MOUNTING PROFILE
WALL MOUNTING
+15° to -5°
800.MOUNT.IT (800.668.6848)
12152011
Packaging UPC MC UPC
Americas 728901023125 728901716577
International 728901023125 728901716577
Box Contents Qty
Spider 44 adapter 4
Complete mount installation hardware kit 1
Complete TV attachment hardware kit 1
Instruction manual 1
Box Contents Qty
Full motion wall plate 1
Full motion arm 1
Monitor plate 1
Cable management channel 2
Wall plate cover 2
Dimensions WxDxH Inches (mm) Wt lbs (kg) Qty
Box 12.4 x 13.8 x 4.1 (316x350x105) 9.9 (4.5) NA
MC 12.9 x 14.8 x 8.7 (328x375x220) 20.9 (9.5) 2
