inches (mm)
4N1-S
technical data sheet
FRONT VIEW
WITH ADAPTERS
MOUNTING PROFILE
WITH ADAPTERS
200
100
7
200
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
WITH ADAPTERS
WALL MOUNTING
MAXIMUM EXTENSION
WITH ADAPTERS
8.4
(212)
2.2
(56)
7.6
(192)
8.7
(220)
10.3
(262)
11.1
(283) 2.5
(62)
Ø .2
(6)
2.6
(65)
4.5
(115)
.6
(16) .6
(15)
1.2
(30)
7.3
(186)
5.7
(144)
FRONT VIEW MOUNTING PROFILE MAXIMUM EXTENSION
75
100
75 100
7
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
-5 TO +15
Box Contents Qty
Wall plate 1
Wall plate cover 1
Arm 1
V200A adapter 4
M8-M5 reducer spacer kit 1
Dimensions WxDxH inches (mm) Wt lbs (kg) Qty
Box 6 x 9.9 x2.8 (152x252x70) 2.5 (1.1) NA
MC 10.3 x 10.4 x 6.3 (262x264x160) 10.5 (4.7) 4
Packaging UPC MC UPC
Americas 728901016745 728901710032
International NA NA
800.MOUNT.IT (800.668.6848)
08032011
Box Contents Qty
Complete mount installation hardware kit 1
Complete panel attachment hardware kit 1
Instruction manual 1
TV compatibility chart 1
