HARDWARE
TOOLS NEEDED
V200A Adapter 4 4
Locking Screw 1 3
Monitor Plate 1 2
Wall Plate 1 1
Description Qty Part #
Contents
Adapter Screws 4 P-A
Description Qty Part #
Screws/Hardware for Product (OM1100155vA)
3
4
1
1/8”
or
5/16”
SCREWS/HARDWARE FOR PRODUCT
(OM1100155vA)
SCREWS / HARDWARE FOR FLAT PANEL
(MONITOR KIT M-V-vD)
M-C M-A
M5
X 4
M6
X 4
M4
X 4
M-B
SCREWS/HARDWARE FOR WALL
(WALL KIT 12-2vB)
W-A
X 2
W-B
X 2
P-A
X 4
Wall Anchor 2 W-B
Philips Wood Screws 2 W-A
Description Qty Part #
Screws / Hardware for Wall Mounting ( Wall Kit 12-2vB )
Philips Screws M6 x 12mm 4 M-C
Philips Screws M5 x 12mm 4 M-B
Philips Screws M4 x 12mm 4 M-A
Description Qty Part #
Screws / Hardware for Flat Panel ( Monitor Kit M-V-vD )
