Omtbk, Line drawing – Omnimount OMTBK Sales Sheet User Manual

Page 3

background image

inches (mm)

800.MOUNT.IT (800.668.6848)

9.5 - 17.3

(240 - 440)

9.5 - 17.4

(241 - 441)

FRONT VIEW

1.9 - 2.7

(47 - 68)

MOUNTING PROFILE

0.8

(20)

9.5 - 15.8

(200 - 400)

7.9 - 15.8

(201 - 401)

0.3

(8)

WALL MOUNTING

+5º

9.5 - 17.3

(240 - 440)

9.5 - 17.4 (241 - 441)

0.8

(20)

OMTBK

line drawing

03212011
