CONTeNTS

Contents

Part # Qty description

1 1 Wall Plate

2 1 Right Rail

3 1 Left Rail

4 2 Tilt Tension Knobs

5 2 Locking Mechanisms

2

1

3

M-A

M-B

M-C

W-A

W-B

M-d

M-e

M-F

M-G

M-H

M-I

M-J

M-K

M-L

W-C

4

SCReWS/HARdWARe FOR

WALL MOUNTING

Part # Qty description

W-A 2 Lag Bolt

W-B 2 Washer

W-C 2 Wall Anchor
