EC Series
Compact Bench Counting Scale
80774391_C
©
Copyright
OHAUS
Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
Physical and Operational Features:
Removable stainless steel weighing pan, clear plastic in-use protective cover, durable ABS plastic housing, shipping
screw to avoid damage to sensitive components, backlit LCD displays, rubber user-adjustable leveling feet, front panel
leveling bubble, internal rechargeable lead acid battery, external AC wall adapter, large dedicated Tare and Sample
keys, dedicated memory, pre-set Tare, APW and Zero keys, numeric keypad, user-selectable Auto-Off, Pre-set Tare,
Auto-optimization of APW, low APW alert, user-selectable environmental filtering, Auto-Zero Tracking, 10 APW
memory locations, Accumulation function with recall of total weight, number of weighments and total parts count.
Industry Leading Quality and Support
Our rugged con struc tion and stringent quality control have been hallmarks of all OHAUS products for over a century.
Specifications
Model EC3 EC6 EC15 EC30
Capacity x Readability
3000 g x 0.1 g
6 lb x 0.0002 lb
6000 g x 0.2 g
15 lb x 0.0005 lb
15000 g x 0.5 g
30 lb x 0.001 lb
30000 g x 1 g
60 lb x 0.002 lb
Minimum Recommended Sample Weight 1 g / 0.002 lb 2 g / 0.005 lb 5 g / 0.01 lb 10g / 0.02 lb
Minimum Recommended APW 0.01 g / 0.00002 lb 0.02 g / 0.00005 lb 0.05 g / 0.0001 lb 0.1 g / 0.0002 lb
Maximum Internal Counting Resolution 1:600,000
Maximum Displayed Resolution 1:30,000
Weighing Units lb or g (menu selected)
Application Modes Weighing, Counting, Accumulation
Display 3-Window, backlit LCD 0.75in / 19mm High, 6-digit, 7-segment
Display Indicators Stability, Center of Zero, Tare, Low Sample Weight, Low APW, Accumulation, Battery Status, Weighing Unit
Memories 10 locations for APW
Keyboard 7 function (Tare, Sample, APW, Zero, Pre-set Tare, M+, Cancel), 11 numeric membrane keys
Tare Range To Full Capacity by Subtraction (except EC15, up to 20 lbs/10kg only)
Stabilization Time ≤ 2 seconds
Auto-Zero Tracking 0 (off), 0.5, 1, 2, 3d
Safe Overload Capacity 150% of capacity
Power AC Adapter (included) / Internal rechargeable lead acid battery (included)
Battery Life 80 hours continuous use with 12 hour recharge time
Calibration External, with user-selectable calibration weight
Operating Temperature 32° to 104° F / 0° to 40° C
Pan Size (in / mm) 11.6 x 8.9 / 294 x 226
Scale Dimensions (in / mm) 12.8 W x 13 D x 4.5 min H / 325 W x 330.5 D x 114 min H
Shipping Dimensions (in / mm) 17.3 W x 14.2 D x 6.3 H / 440 W x 360 D x 160 H
Net Weight (lb / kg) 9.2 / 4.2
Shipping Weight (lb / kg) 11.7 / 5.3
