Model FD3 FD6 FD15
Capacity x Default Readability
3 kg x 0.0005 kg
3,000 g x 0.5 g
6 lb x 0.001 lb
96 oz x 0.02 oz or 1/4 oz
6 lb:0 oz x 0.1 oz or 1/4 oz
3 kg x 0.001 kg
6 kg x 0.001 kg
6,000 g x 1 g
15 lb x 0.002 lb
240 oz x 0.05 oz or 1/4 oz
15 lb:0 oz x 0.1 oz or 1/4 oz
6 kg x 0.002 kg
15 kg x 0.002 kg
15,000 g x 2 g
30 lb x 0.005 lb
480 oz x 0.1 oz or 1/4 oz
30 lb:0 oz x 0.1 oz or 1/4 oz
15 kg x 0.005 kg
Capacity x Readability
Certified/Approved*
3,000 g x 1 g
6 lb x 0.002 lb
96 oz x 0.05 oz or 1/4 oz
6,000 g x 2 g
15 lb x 0.005 lb
240 oz x 0.1 oz or 1/4 oz
15,000 g x 5 g
30 lb x 0.01 lb
480 oz x 0.2 oz or 1/4 oz
Model FD3H FD6H FD15H
Capacity x Readability
Maximum Displayed Readability
3 kg x 0.0001 kg
3,000 g x 0.1 g
6 lb x 0.0002 lb
96 oz x 0.005 oz
96 oz x 1/4 oz
6 lb 0 oz x 0.1 oz
6 lb 0 oz x 1/4 oz
6 kg x 0.0002 kg
6,000 g x 0.2 g
15 lb x 0.001 lb
240 oz x 0.01 oz
240 oz x 1/4 oz
15 lb 0 oz x 0.1 oz
15 lb 0 oz x 1/4oz
15 kg x 0.001 kg
15,000 g x 1 g
30 lb x 0.001 lb
480 oz x 0.02 oz
480 oz x 1/4 oz
30 lb 0 oz x 0.1 oz
30 lb 0 oz x 1/4 oz
Weighing Units
Pound, decimal ounce, 3/4, 1/2 and 1/4 fractional ounce, gram, kilogram,
combined lb:oz display (either decimal or fractional ounces)
Application Modes Weighing, Checkweighing, Percent Weighing
Display 0.75-in (19mm) high 5-digit, 7-segment backlit blue LCD display
Display Indicators Stability, center of zero, tare or net weight, battery status, checkweigh mode
Checkweighing Indicators 3 LED (yellow, green, red) with configurable operation and alert beeper
Keyboard 4 – button membrane switch
Environmental Protection IP 43
Tare Range Full Capacity by Subtraction
Stabilization Time < 2 seconds
Auto-Zero Tracking Off, 0.5, 1 or 3 divisions
Overload Capacity 150% of capacity
AC Power 9 VDC 0.5A AC Wall Adapter100-120 V AC, 50/60 Hz
Battery Internal rechargeable sealed lead-acid battery with 120 hours continuous use
Calibration User-selectable external span or linearity calibration
Operating Temperature and Humidity
Range
14° to 104°F / -10° to 40°C, 10 to 85% relative humidity, non-condensing
Pan Size 8.2 x 8.2 in / 209 x 209 mm
Scale Dimensions WxHxD 9 x 12 x 2.8 in / 300 x 223 x 71 mm
Shipping Dimensions WxHxD 15.8 x 12.6 x 7.3 in / 400 x 320 x 185 mm
Net Weight 8 lb / 3.6 kg
Shipping Weight 11 lb / 5 kg
* lb:oz display not available in legal-for-trade application mode.
FD Series
Food Portioning Scale
Physical Features
Stainless steel top and bottom housings, dishwasher safe stainless steel pan, backlit LCD display, rubber user-adjustable
leveling feet, front panel leveling bubble, internal rechargeable lead-acid battery, external AC wall adapter, weight/mode
stability/center of zero/net weight/tare weight/text unit indication, 4-bar battery status indicator with low-battery warning,
3 LED’s and buzzer for use in checkweighing mode, dedicated tare key, audible buzzer with user-selectable volume control,
selectable scale auto-off, sealable scale configuration and calibration lockout switch
.
Operational Features
Selectable environmental averaging settings, backlight control with auto-off option, selectable weighing units, configurable
checkweighing mode, configurable software lockout menu, span or linearity calibration in kg or lb unit with optional exter-
nal masses, semi-automatic or automatic tare, selectable auto-zero tracking.
Accessories
Foot switch (p/n 71169633); hard shell carry case (p/n 80251394); flat pan (p/n 80251141); in-use cover (p/n 80251140)
Compliance
• Food Service: NSF Listed/Certified to NSF/ANSI 169-2005 Special Purpose Food Equipment and Devices (formerly NSF C-2);
USDA/AMS Accepted to NSF/3-A 14159-1 Hygiene Requirements for the Design of Meat and Poultry Processing Equipment;
meets requirements for HACCP conformity.
• Electrical/Emissions: UL C US listed, meets AS/NZS4251.1 Emission/AS/NZS4252.1 Immunity, FCC Class B Part 15 operation,
Industry Canada Class B.
• Legal-for-Trade: Non-H models are NTEP certified (CC No. 05-072A1), Measurement Canada approved (No. AM-5582).
• Quality: OHAUS quality management system registered to ISO 9001:2008
