Defender Series Base EN-3
TABLE 2. SPECIFICATIONS
MODEL D250TX D500TX
Capacity 250 kg / 500 lb 500 kg / 1000 lb
Approved Resolution 2500d
Non-approved Resolution 5000d
Safe Overload Capacity 150% of capacity
Pan Dimensions 508 x 710 mm / 20 x 28 in.
Base Dimensions 520 x 720 x 198 mm / 20.5 x 28.3 x 7.8 in.
Base Construction 304 stainless steel platform with painted steel frame and polyurethane wheels
Repeatability (std. deviation) 1d
Linearity ±1d
Load Cell Capacity 500 kg 1000 kg
Load Cell Cable 2 m L x 4-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Net Weight 40 kg / 88 lb
Shipping Weight 46 kg / 101 lb
Drawing
Figure 1. Defender Base Dimension Drawing.
