3
ASSEMBLY ASSEMBLY ASSEMBLY ASSEMBLY ASSEMBLY
When the Scale Base is to be used with an OHAUS I20W Washdown Indicator, connect
the Load Cell cable to the Indicator as indicated in the table.
DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION COLOR COLOR COLOR COLOR COLOR
WB Series WBS Series
+ Excitation Green Red
- Excitation Black Black
+ Output Red Green
- Output White White
Ground Shield Shield
APPROVALS APPROVALS APPROVALS APPROVALS APPROVALS
The WB and WBS Series of Washdown Scale Bases meet the requirements of NIST
Handbook 44, as listed below:
Certificate of conformance 88-204 was issued for the WB Series and Certificate of
Conformance 88-205 was issued for the WBS Series under the National Type
Evaluation Program of the National Conference on Weights and Measures.
MODEL MODEL MODEL MODEL MODEL TYPE APPROVED CAPACITY X RESOLUTION TYPE APPROVED CAPACITY X RESOLUTION TYPE APPROVED CAPACITY X RESOLUTION TYPE APPROVED CAPACITY X RESOLUTION TYPE APPROVED CAPACITY X RESOLUTION
WB10 10 lb 0.002 lb
WB25 25 lb 0.005 lb
WB50 50 lb 0.01 lb
WBS10 10 lb 0.005 lb
WBS25 25 lb .01 lb
WBS50 50 lb .02 lb
The WB and WBS Series have also been approved by the U.S. Department of
Agriculture for use in Federally inspected meat and poultry processing plants.
UNPACKING AND SET UP UNPACKING AND SET UP UNPACKING AND SET UP UNPACKING AND SET UP UNPACKING AND SET UP
1. Carefully remove the Scale Base from the packing material and place it on a level
and stable surface.
2. Remove the stainless steel Platform and set it aside.
3. Locate the Level Indicator on the Sub-Platform.
4. The Level Indicator bubble should be totally enclosed by the scribed inner circle.
If leveling is required, loosen the locking Nuts of the four Leveling Feet and adjust
them until the Load Receiver is level. Retighten the Locking Nuts when leveling
has been completed.
5. Place the Platform on the Sub-Platform.
NOTE NOTE NOTE NOTE NOTE: It is recommended that the packing material be saved for use when storing or
transporting the Scale Base.
