CKW Series
Checkweighing Scale Base
80774494_A © Copyright OHAUS Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
Specifications
Models CKW3R CKW6R CKW15L CKW30L
Capacity (max) x Enhanced
Readability
6 lb x .001 lb
3 kg x 0.5g
15 lb x .002 lb
6 kg x 1 g
30 lb x .005 lb
15 kg x 2 g
60 lb x .01 lb
30 kg x 5 g
Maximum Displayed Resolution 1:6000 1:7500 1:7500 1:6000
Capacity (max) x
Approvable Readability
6 lb x 0.002 lb
3 kg x 0.001 kg
15 lb x 0.005 lb
6 kg x 0.002 kg
30 lb x 0.01 lb
15 kg x 0.005 kg
60 lb x 0.02 lb
30 kg x 0.01 kg
Approval Resolution 1:3000 1:3000 1:3000 1:3000
Platform Dimensions
(WxDxH)
10 x 10 x 2.3 in /
254 x 254 x 57.5 mm
12 x 12 x 2.3 in /
305 x 305 x 57.5 mm
12 x 12 x 2.7 in /
305 x 305 x 69.5 mm
Load Cell Capacity 6 kg 10 kg 30 kg 50 kg
Safe Overload Capacity 150% of rated capacity
Protection Load Cell: IP67, Indicator: NEMA 4X / IP66
Operating Temperature Range 14°F to 104°F / -10°C to 40°C
Net Weight 11.2 lb / 5.1 kg 13.3 lb / 6.2 kg 18.3 lb / 8.3 kg 20.5 lb / 9.3 kg
Shipping Dimensions
(W x D x H)
17.7 x 15.3 x 9.8 in /
450 x 390 x 250 mm
17.7 x 15.3 x 9.8 in /
450 x 390 x 250 mm
17.7 x 15.3 x 9.8 in /
450 x 390 x 250 mm
17.7 x 15.3 x 9.8 in /
450 x 390 x 250 mm
Shipping Weight 15.4 lb / 7 kg 17.9 lb / 8.1 kg 22.7 lb / 10.3 kg 24.9 lb / 11.3 kg
Options and Accessories OHAUS Number
Wall Mount Bracket Kit for CKW Scale ...................................................................................71167964
Stainless Steel Column Mount Kit 9 in (230mm) Tall, CKW ...................................................71167972
Stainless Steel Column Mount Kit 26 in (680mm) Tall, CKW .................................................80251059
Physical Features
Base features stainless steel frame and loadcell, removable stainless steel platform, stainless steel indicator mounting column, rubber
user-adjustable leveling feet and externally-visible leveling bubble, and overload stops to protect loadcell.
Approvals/Listings/Certifications
• Food Processing and Service: NSF Listed/Certified to NSF/ANSI 169-2005 Special Purpose Food Equipment and Devices
(formerly NSF C-2); USDA/AMS Accepted to NSF/3-A 14159-1 Hygiene Requirements for the Design of Meat and Poultry
Processing Equipment; meets requirements for HACCP conformity
• Legal-for-Trade:
NTEP CC No. 06-030
Measurement Canada Approval No. AM-5607
OIML R60 2000-NL1-03.24 / R60 2000-NL-02.14 (load cell)
• Quality: Ohaus quality management system registered to ISO 9001:2008
