Ohaus TROOPER COMPACT COUNTING SCALES Data Sheet - Manual (Page 4)

Trooper
®
TC Series
Counting Scales
80774398_B © Copyright OHAUS Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
Specifications
Models without Printer
TC3RS TC6RS TC15RS TC30RS
Models with Printer TC3RSP TC6RSP TC15RSP TC30RSP
Capacity (max) x
Default Readability
6 lb x 0.001 lb
3 kg x 0.0005 kg
3,000 g x 0.5 g
96 oz x 0.02 oz
15 lb x 0.002 lb
6 kg x 0.001 kg
6,000 g x 1 g
240 oz x 0.05 oz
30 lb x 0.005 lb
15 kg x 0.002 kg
15,000 g x 2 g
480 oz x 0.1 oz
60 lb x 0.01 lb
30 kg x 0.005 kg
30,000 g x 5 g
960 oz x 0.2 oz
NTEP Certified
Capacity x Readability* 6 lb x 0.002 lb
3 kg x 0.001 kg
15 lb x 0.005 lb
6 kg x 0.002 kg
30 lb x 0.01 lb
15 kg x 0.005 kg
60 lb x 0.02 lb
30 kg x 0.01 kg
Minimum APW with Auto Add
0.0002 lb
0.0001 kg
0.0005 lb
0.0002 kg
0.001 lb
0.0005 kg
0.002 lb
0.001 kg
Minimum APW without Auto Add
0.00006 lb
0.00003 kg
0.00015 lb
0.00006 kg
0.0003 lb
0.00015 kg
0.0006 lb
0.0003 kg
Maximum Displayed Resolution 1:6,000 to 1:7,500 depending on model
Maximum Counting Resolution 1:30,000 with Auto Add, 1:100,000 without Auto Add
Construction ABS plastic housing, stainless steel weighing pan
Platform Size (W x D) 13.5 in x 9 in / 34 cm x 23 cm
Leveling Components Four adjustable rubber feet with integral rear mounted level bubble
Stabilization Time 4 seconds or less
Keyboard 10 function, 11 numeric membrane keys with audible key press feature
Weighing Units lb, kg, g, oz
Weighing Modes Piece counting, basic weighing, count checking, checkweighing
Display
7-segment, 0.5 in / 12 mm high digits:
5-digit Weight, 6-digit Data and 6-digit Count backlit LCD displays
Power Supply (Scale) AC Adapter (included) or 6 “C” batteries (not included) for up to 100 hours normal operation
Span Calibration 1/3, 2/3 or full capacity
Auto Zero Tracking Off, 0.5, 1 or 3 divisions
Operating Temperature 41° F to 104° F / 5° C to 40° C
Storage Temperature -40° F to 140° F / -40° C to 60° C
Scale Dimensions (W x D x H) 13.5 x 14.5 x 4.5 in / 343 x 368 x 114 mm
Printer Dimensions (W x D x H) 3.9 x 7.5 x 3.5 in / 100 x 191 x 90 mm
Shipping Dimensions (W x D x H) 17 x 17 x 8.5 in / 422 x 422 x 216 mm
Net Weight (Bundled) 8.6 lb / 3.9 kg for TC models / 11.2 lb / 5.1 kg for TCP models
Shipping Weight (Bundled) 11.8 lb / 5.4 kg for TC models / 14.4 lb / 6.5 kg for TCP models
*NTEP Certification for weighing function only
Standard Features
Stainless steel weighing pan, internal aluminum frame, ABS plastic housing, 3-window backlit LCD display; 21-key
membrane keys with numeric keypad and dedicated counting keys; Leveling feet and bubble; RS232 bi-directional
interface; Auto-off timer; User-selectable audible key beep; Low battery warning; Auto-zero tracking; Software
lockout of menu settings; Hardware lockout for LFT use.
Counting Features
Positive and Negative sampling, with user input of sample size or default sample size of 10; positive and negative
counting; manual or pre-set tares; selectable memory mode for single part file operation; auto-optimization of average
piece weight; auto-add to ensure sample weight accuracy; 60 part files with input for 12-digit part number, average
piece weight, tare weight, over / under values and count accumulation; programmable over/under limits with audible
beep and LCD indication.
TCP models include model 80251992 direct thermal printer and RS232 cable.
Compliance/Certifications
Scale: UL, FCC, CSA, CE
Printer and power adapter: CE, TUV-GS, FCC, VCCI,
C
UL
US
, PSE
NTEP (CC No. 02-0092A), Measurement Canada (Notice of Approval AM-5449), for weighing only
Industry Leading Quality and Support
All OHAUS Trooper
® Counting Scales are manufactured under an ISO 9001:2008 Registered Quality Management
System. Our rugged con struc tion and stringent quality control have been hallmarks of all OHAUS products for
over a century.
