EC Series EN-5
3 OVERVIEW OF CONTROLS AND FUNCTIONS
3.1 Display Symbols
• Weight Window - displays weight of object on
weighing pan, or accumulated weight value
• Center of Zero Indication
• Tare or Pre-set Tare (PT) Indication
• Piece Weight Window - displays the Average
Piece Weight (APW) value, or number of
weighments
• Low Sample Weight Indication - total sample
weight is less than 10 display divisions, add
more samples for more accurate reading
• Low Average Piece Weight Indication - calculated
APW is less than 1/10 display divisions, unit
weight is too small for ensuring accurate quantity
calculations
• Piece Count Window - displays the calculated
number of pieces on the weighing pan, or
accumulated piece count value
• Scale is in Accumulation mode
• Low battery charge, recharge battery
• Stable Indication, scale is in stable condition
• Battery Charging Indication:
o Green – battery is fully charged
o Yellow – battery is partially charged and
charging
o Red – battery is nearly discharged
“WEIGHT”
“PIECE WEIGHT”
“Wt. Lo”
“APW Lo”
“COUNT”
“STB”
o LED
STB
APW
Lo
Wt.
Lo
Weight g Piece Weight g/pc Count pcs
