OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
80774522_B © Copyright Ohaus Corporation
Defender
TM
3000
Wheeled Bench Scales
Accessories Ohaus Number
RS232 Interface cable to PC 25-pin ........................................80500524
RS232 Interface cable to PC 9-pin ..........................................80500525
RS232 Interface cable to 80252042 dot matrix printer...........80252571
RS232 Interface cable to 80251992 thermal printer ...............80252581
Compact dot matrix impact printer .........................................80252042
Compact thermal printer .........................................................80251992
Approvals:
• Safety:
C
UL
US
, CE
• EMC: FCC, ICES, CE Class A
• Legal for Trade: NTEP CC 08-066 A1 (indicator) / CC 09-056 (base)
Measurement Canada AM-5713C Rev. 1 (indicator) / AM-5723 (base)
• Quality: OHAUS quality management system registered to ISO 9001:2008
Outline Dimensions
28.3 in. /
720 mm
3.5 in
90 mm
20 in
508 mm
16.5 in
418 mm
20.5 in
520 mm
7.8 in
198 mm
28 in
710 mm
21.4 in
544 mm
28.3 in
720 mm
35.8 in
910 mm
51 in
1295 mm
28.3 in. /
720 mm
3.5 in
90 mm
20 in
508 mm
16.5 in
418 mm
20.5 in
520 mm
7.8 in
198 mm
28 in
710 mm
21.4 in
544 mm
28.3 in
720 mm
35.8 in
910 mm
51 in
1295 mm
Specifications
Scale Models D31P250TX D31P500TX
Capacity x Readability (default: cal unit lb)
Capacity x Readability (cal unit kg)
500 lb x 0.1 lb / 227 kg x 0.05 kg
250 kg x 0.05 kg / 551 lb x 0.2 lb
1,000 lb x 0.2 lb / 454 kg x 0.1 kg
500 kg x 0.1 kg / 1,102 lb x 0.5 lb
Capacity x Certified/Approved Readability
500 lb x 0.2 lb
250 kg x 0.1 kg
1,000 lb x 0.5 lb
500 kg x 0.2 kg
Pan Dimensions (W x D) 20 x 28 in / 508 x 710 mm
Base Construction 304 stainless steel pan with painted steel frame, polyurethane wheels with locking mechanism, external level indicator
Column 40.5 in (1,030 mm), fixed height tubular painted steel with handle bar
Safe Overload Capacity 150% of rated capacity
Load Cell 350 Ω, IP67 aluminum, 2mV/V, 5-15V DC/AC
Indicator T31P indicator with ABS plastic housing and painted carbon steel U-mount bracket with angle adjustment knobs
Weight Display 1 in (25 mm) high, 6-digit, 7-segment LCD with high-contrast white LED backlight
Weighing Units lb, oz, lb-oz, kg, g
Extra Functions/Modes Parts Counting (min APW 1d)
Keyboard 4 function mechanical switches, raised with positive feedback
Stabilization Time Within 2 seconds
Auto-zero Tracking Off, 0.5, 1 or 3 divisions
Zeroing Range 2% or 100% of capacity
Span Calibration 5 lb/kg to 100% of capacity
Interface Bi-directional RS232
Operating Temperature Range 14˚F to 104˚F / -10˚C to 40˚C
Power 9-12 VDC, 0.5A, AC adapter with internal rechargeable lead acid battery (100-hour typical operation on full charge)
Scale Net Weight 88 lb / 40 kg
Shipping Dimensions (W x D x H) 30.7 x 46.1 x 10.6 in / 780 x 1170 x 270 mm
Shipping Weight 101 lb / 46 kg
