Navigator XL
Model NVL511/1 NVL1101/1 NVL2101/1 NVL5101/1 NVL10000/1 NVL20000/1
Capacity × Maximum Displayed
Readability
510 g × 0.1 g
1.1 lb × 0.0005 lb
18 × 0.005 or 1/8 oz
––
1,100 g × 0.1 g
2.4 lb × 0.0005 lb
38.8 × 0.005 or 1/8 oz
1.1 kg × 0.0001 kg
2,100 g × 0.1 g
4.6 lb × 0.0005 lb
74 × 0.005 or 1/8 oz
2.1 kg × 0.0001 kg
5,100 g × 0.5 g
11.2 lb × 0.002 lb
179.9 × 0.02 or 1/8 oz
5.1 kg × 0.0005 kg
10,000 g × 1 g
22 lb × 0.005 lb
352 × 0.05 or 1/8 oz
10 kg × 0.001 kg
20,000 g × 1 g
44 lb × 0.005 lb
705.5 × 0.05 or 1/8 oz
20 kg × 0.001 kg
Displayed Resolution (g) 1:5100 1:11000 1:21000 1:10200 1:10000 1:20000
Repeatability / Linearity 0.1 g / ±0.2 g 0.1 g / ±0.2 g 0.1 g / ±0.2 g 0.5 g / ±1 g 1 g / ±2 g 1 g / ±2 g
Span Calibration Mass 1 300 g 1 lb / 500 g 2 lb / 1 kg 5 lb / 3 kg 10 lb / 5 kg 20 lb / 10 kg
Linearity Calibration Mass 1 300 g, 500 g
1 lb, 2 lb
500 g, 1000 g
2 lb, 5 lb
1 kg, 2 kg
5 lb, 10 lb
3 kg, 5 kg
10 lb, 20 lb
5 kg, 10 kg
20 lb, 50 lb
10 kg, 20 kg
Battery Power
Internal rechargeable lead acid battery, 6V1.2AH (100-hour typical operation with
12-hour full charge) or 4C (LR14) batteries (not included)
Platform Size (W × D) 7.6 × 8 in / 194 × 203 mm
Scale Dimensions (W × D × H) 8 Ч 11.1 Ч 2.9 in / 204 Ч 282 Ч 74 mm
Shipping Dimensions (W x D x H) 16 Ч 12.8 Ч 6.7 in / 390 Ч 325 Ч 170 mm
Net Weight 4.3 lb / 2.0 kg
Shipping Weight 6.1 lb / 2.8 kg
General Specifications
Stabilization Time ≤1 second
Tare Range Full capacity by subtraction
AC Power 12VDC 0.42A AC adapter (included), 100-240V 0.25A 50-60Hz
Calibration User-selectable external span or linearity calibration / Digital with external weight
Application Modes Weighing, Percent Weighing, Parts Counting, Check Weighing, Display Hold, Accumulate/Totalize
Weighing Units*
Gram, Kilogram, Pound, Ounce (decimal or fractional), Pound:Ounce (decimal or fractional), Ounce Troy,
Grain, Newton, Carat, Pennyweight, Hong Kong Tael, Taiwan Tael, Singapore Tael, Tical, Tola
Display Type Backlit LCD: 6-digit 7-segment with white LED backlight
Display Size 0.78 in / 20 mm digits
Checkweigh Indicators Over/Accept/Under LCD annunciators
Keypad 4 mechanical keys, raised and with tactile feedback plus 2 touchless sensors
Leveling Adjustment Front-mounted level bubble with illumination / adjustable leveling feet with skid-resistant rubber pads
Overload Capacity 400% of rated capacity
Power Conservation User-enabled, auto power-off after 5 minutes of inactivity
Operating Conditions 50°F to 104°F / 10°C to 40°C at 20% to 85% relative humidity, non-condensing
*NV212 no kg or lb units; NV511 / NVL511 no kg units
Navigator
Model NV212 NV511 NV1101 NV2101 NV4101 NV5101
Capacity × Maximum
Displayed Readability
210 g × 0.01 g
––
7.4 oz × 0.0005
or 1/8 oz
510 g × 0.1 g
1.1 lb × 0.0005 lb
18 oz × 0.005 or 1/8
oz
––
1,100 g × 0.1 g
2.4 lb × 0.0005 lb
38.8 oz × 0.005 or
1/8 oz
1.1 kg × 0.0001 kg
2,100 g × 0.1 g
4.6 lb × 0.0005 lb
74 oz × 0.005 or
1/8 oz
2.1 kg × 0.0001 kg
4,100 g × 0.2 g
9 lb × 0.0005 lb
144.6 oz × 0.01 or
1/8 oz
4.1 kg × 0.0002 kg
5,100 g × 0.5 g
11.2 lb × 0.002 lb
179.9 oz × 0.02 or
1/8 oz
5.1 kg × 0.0005 kg
Displayed Resolution (g) 1:21000 1:5100 1:11000 1:21000 1:20500 1:10200
Repeatability / Linearity 0.01 g / ±0.02 g 0.1 g / ±0.2 g 0.1 g / ±0.2 g 0.1 g / ±0.2 g 0.2 g / ±0.4 g 0.5 g / ±1 g
Span Calibration Mass 1 200 g 300 g 500 g 1 kg 2 kg 3 kg
Linearity Calibration
Mass 1
100, 200 g 300, 500 g 500 g, 1 kg 1, 2kg 2, 4kg 3, 5kg
Battery Power 4 AA (LR6) batteries (not supplied)
Platform Size (Dia.) 4.7 in / 120 mm 7.5 × 5.4 in / 190 × 138 mm
Scale Dimensions
(W × D × H)
8 Ч 8.4 Ч 2.3 in / 204 Ч 212 Ч 58 mm
Shipping Dimensions
(W × D × H)
12 Ч 10 Ч 5.3 in / 305 Ч 255 Ч 134 mm
Net Weight 3.1 lb / 1.4 kg
Shipping Weight 4.2 lb / 1.9 kg
1 Calibration weights not included; contact OHAUS to purchase separately
