Defender
®
3000 Xtreme
Washdown Bench Scales
80774334_I © Copyright Ohaus Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout
Europe, Asia, and
Latin America
*ISO 9001:2008
Registered Quality
Management System
Models D32XW30VR D32XW60VR D32XW60VL D32XW150VL D32XW150VX D32XW300VX
Capacity x Readability (d) 66 lb x 0.01 lb
1056 oz x 0.2 oz
66 lb x 0.2 oz (lb:oz)
30 kg x 0.005 kg
30,000 g x 5 g
132 lb x 0.02 lb
2,112 oz x 0.5 oz
60 kg x 0.01 kg
60,000 g x 10 g
132 lb x 0.02 lb
2,112 oz x 0.5 oz
60 kg x 0.01 kg
60,000 g x 10 g
330 lb x 0.05 lb
5,280 oz x 1 oz
150 kg x 0.02 kg
150,000 g x 20 g
330 lb x 0.05 lb
5,280 oz x 1 oz
150 kg x 0.02 kg
150,000 g x 20 g
660 lb x 0.1 lb
10,576 oz x 2 oz
660 lb x 2 oz (lb:oz)
300 kg x 0.05 kg
300,000 g x 50 g
Capacity x Readability (d)
(Cal unit lb)
60 lb x 0.01 lb
960 oz x 0.2 oz
60 lb x 0.2 oz (lb:oz)
27 kg x 0.005 kg
27,000 g x 5 g
150 lb x 0.02 lb
2,400 oz x 0.5 oz
68 kg x 0.01 kg
68,000 g x 10 g
150 lb x 0.02 lb
2,400 oz x 0.5 oz
68 kg x 0.01 kg
68,000 g x 10 g
300 lb x 0.05 lb
4,800 oz x 1 oz
300 lb x 1 oz (lb:oz)
136 kg x 0.02 kg
136,000 g x 20 g
300 lb x 0.05 lb
4,800 oz x 1 oz
300 lb x 1 oz (lb:oz)
136 kg x 0.02 kg
136,000 g x 20 g
600 lb x 0.1 lb
9,600 oz x 2 oz
600 lb x 2 oz (lb:oz)
272 kg x 0.05 kg
272,000 g x 50 g
Displayed Resolution 1:6,000 1:7,500 1:7,500 1:7,500 1:7,500 1:6,000
Load Cell Protection NEMA 4X / IP65
Base Construction 304 stainless steel pan with stainless steel frame, non-slip rubber leveling feet
Platform Dimensions
(W x D x min H)
12 x 14 x 4.8 in / 305 x 355 x 123 mm 16.5 x 21.6 x 5.4 in / 420 x 550 x 136 mm 19.7 x 25.6 x 5.8 in / 500 x 650 x 147 mm
Front View Dimensions
(F1 x F2 x F3 x F4 x F5)
8.2 x 6.5 x 12 x 4.8 x 3 x 10 in
210 x 166 x 305 x 119 x 75 x 256 mm
8.2 x 6.5 x 16.5 x 5.4 x 3.2 x 14.6 in
210 x 166 x 420 x 145 x 80 x 371 mm
8.2 x 6.5 x 19.7 x 5.6 x 3.5 x 17.3 in
210 x 166 x 500 x 154 x 90 x 440 mm
Side View Dimensions
(S1 x S2 x S3 x S4 x S5)
22.5 x 18.6 x 14 x 12 x 2 in
572 x 472 x 355 x 306 x 52 mm
36.2 x 26.3 x 21.7 x 19.7 x 2 in
920 x 668 x 550 x 500 x 52 mm
36.2 x 29.1 x 25.6 x 23.2 x 2 in
920 x 740 x 650 x 590 x 52 mm
Column 13.8 in / 350 mm fixed height, stainless steel 27.6 in / 700 mm fixed height, stainless steel
Leveling Component Externally visible level bubble and adjustable leveling feet with locking nuts
Safe Overload Capacity 125% of rated capacity
Indicator Construction Stainless steel
Weighing Units lb, oz, lb:oz, kg, g
Functions Weighing, Parts Counting
Weight Display 6-digit, 7-segment backlit LCD, 1 inch / 25 mm high digits
Keyboard 4 function mechanical keys, raised, tactile
Stabilization Time Within 2 seconds
Auto-zero Tracking Off, 0.5, 1 or 3 divisions
Key Zeroing Range 2% or 100% of capacity
Span Calibration 5 lb/kg to 100% of capacity, user selectable
Power 100 - 240 VAC/50-60 Hz internal switching power supply with internal rechargeable sealed lead-acid battery (58-hour typical operation with full charge)
Interface Bidirectional RS232C
Operating Temperature
Range
14°F to 104°F / -10°C to 40°C, Maximum relative humidity 80 % for temperatures up to 88°F / 31°C,
decreasing linearly to 50 % relative humidity at 104°F / 40°C, non condensing
Net Weight 33 lb / 15 kg 53 lb / 24 kg 60 lb / 27 kg 84 lb / 38 kg
Shipping Weight 41 lb / 19 kg 61 lb / 28 kg 67 lb / 30 kg 96 lb / 44 kg
Shipping Dimensions 25.3 x 19.6 x 8.5 in / 642 x 497 x 212 mm 33.7 x 22.2 x 8.9 in / 857 x 564 x 225 mm 40.2 x 27 x 9.7 in / 1022 x 687 x 247 mm
Outline Dimensions
Features
Stainless steel housing with backlit LCD weight display, tactile membrane switches, built-in bidirectional RS232C
with manual/continuous/interval printing, hardware configuration lockout switch, internal universal switching
power supply and internal sealed lead-acid rechargeable battery. Software included for parts counting mode
with selectable sample sizes, selectable span calibration points, averaging level, auto-zero tracking, power saving
auto-off, Geo Code geographical gravity calibration adjustment and software menu lockouts. Stainless steel pan
with stainless steel tubular frame, non-slip rubber leveling feet with locking nuts, externally visible level bubble,
stainless steel IP67 load cell, down-stops for overload protection, hollow tubular stainless steel columns.
Compliance
• Safety and EMC: EN60950, EN61326,
FCC Class A, CE (AC adapter),
c
UL
us
• Quality: OHAUS quality management
system registered to ISO 9001:2008
