DEFENDER SERIES SCALES
Base Mount Assembly Instructions
*80251420*
P/N 80251420 A
© Ohaus Corporation 2008, all rights reserved.
Printed in China
(For instructions refer to User Manual)
Connect Load Cell
Connector to Indicator
Install Indicator
Secure cable with tie-wrap as necessary
Complete the scale set-up. Follow the
Assembly Instructions included with your Scale
Reverse the Indicator Top Cover
5
6
7
8
Note: Ensure cables
do not interfere with Platform.
Note: ensure cables
do not interfere with Platform.
17 mm
