Ranger
®
Count 3000
Counting Scales
Other Standard Features and Equipment
30 item library (stores 12-digit part numbers, average piece weights, checkcounting or checkweighing
parameters, tare weights and accumulated weights or counts), auto tare, APW Auto-Optimization and low
APW alert, transportation handle, sealed front panel, menu lockswitch, up-front level indicator, adjustable
leveling feet, selectable environmental and auto-print settings, stability indicator, overload and underload
indicators, low battery indicator, auto shut-off, auto tare
Approvals
• Metrology: NIST Handbook 44 (NTEP CC 13-022), Measurement Canada Weights and Measures Regulations
(AM-5907C) and OIML R76-1 (R76/2006-NL1-12.46), (Class III, n
max
3000) (Counting function not certified/approved)
• Product Safety: CSA C22.2 61010-1, UL 61010-1
• Electromagnetic Compatibility: FCC Part 15 Class A, IEC 61326-1 (emissions Class B, immunity Industrial
requirements)
Accessories
Second Scale, Kit . . . . . . . . . . . . . . . . . . . 30037446
Ethernet Kit . . . . . . . . . . . . . . . . . . . . . . . . . 30037447
Second RS232 Kit . . . . . . . . . . . . . . . . . . . 30037448
USB Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30037449 Weigh Below Hook . . . . . . . . . . . . . . . . . 30037450
In Use Cover . . . . . . . . . . . . . . . . . . . . . . . . 30037451
SF40A Impact Printer with cable . . . 30064203
Model RC31P1502 RC31P3 RC31P6 RC31P15 RC31P30
Default Capacity × Readability 1.5 kg × 0.00005 kg
3 lb × 0.0001 lb
1,500 g × 0.05 g
48 oz × 0.002 oz
3 kg × 0.0001 kg
6 lb × 0.0002 lb
3,000 g × 0.1 g
96 oz × 0.005 oz
6 kg × 0.0002 kg
15 lb × 0.0005 lb
6,000 g × 0.2 g
240 oz × 0.01 oz
15 kg × 0.0005 kg
30 lb × 0.001 lb
15,000 g × 0.5 g
480 oz × 0.02 oz
30 kg × 0.001 kg
60 lb × 0.002 lb
30,000 g × 1 g
960 oz × 0.05 oz
Certified Capacity × Readability 1.5 kg × 0.0005 kg
3 lb × 0.001 lb
1,500 g × 0.5 g
48 oz × 0.02 oz
3 kg × 0.001 kg
6 lb × 0.002 lb
3,000 g × 1 g
96 oz × 0.05 oz
6 kg × 0.002 kg
15 lb × 0.005 lb
6,000 g × 2 g
240 oz × 0.1 oz
15 kg × 0.005 kg
30 lb × 0.01 lb
15,000 g × 5 g
480 oz × 0.2 oz
30 kg × 0.01 kg
60 lb × 0.02 lb
30,000 g × 10 g
960 oz × 0.5 oz
Min. Recommended Sample Weight 1 g 2 g 4 g 10 g 20 g
Min. Recommended APW 0.005 g 0.01 g 0.02 g 0.05 g 0.1 g
Max. Internal Counting Resolution 1:1,500,000 Internal / 1:300,000 External
Maximum Displayed Resolution 1:30,000 1:30,000 1:30,000 1:30,000 1:30,000
Certified/Approved Resolution 1:3,000 1:3,000 1:3,000 1:3,000 1:3,000
Construction ABS housing, stainless steel platform
Weighing Units kg, g, lb, oz, lb:oz
Application Modes Weighing, Parts Counting, Checkweighing, Checkcounting, Accumulation
Display 3-Window, 1 in. / 26 mm high LCD display with white backlight, 6-digit, 7-segment
Checkweighing Indicators 3 LED (yellow, green, red) with configurable operation and alert beeper
Memory 30 item library
Keypad 8 function, 12 numeric mechanical keys
Zero Range 2% or 10% of full scale capacity
Tare Range Full capacity by subtraction
Stabilization Time 1 second
Auto-Zero Tracking Off, 0.5, 1 or 3 divisions
Safe Overload Capacity 150% of capacity
Power 100-240 VAC / 50-60 Hz internal universal power supply, internal rechargeable lead acid battery
Battery Operation 210 hours continuous use between recharges with 12 hour recharge time
Calibration External, with user-selectable calibration weight
Interface Built-in RS232, optional 2 nd platform, 2 nd RS232, USB, Ethernet
Operating Temperature Range 14° F to 104° F / -10° C to 40° C
Platform Size (W × L) 11.8 x 8.9 in. / 300 × 225 mm
Scale Dimensions (W × L × H) 12.2 x 12.9 x 4.6 in. / 311 Ч 327 Ч 117 mm
Shipping Dimensions (W × L × H) 15.6 x 17.6 x 7.7 in. / 397 Ч 447 Ч 195 mm
Net Weight 9.2 lb / 4.2 kg
Shipping Weight 12 lb / 5.45 kg
